| Model: SA1810 Specifications |
| Outlets |
10 |
| Load Rating |
15 Amps @ 120 Volts |
| Power Requirement (no load) |
10 watts |
| Surge Let-Through Voltage (6000-volt surge) |
0 volts |
| UL 1449 Adjunct Classification Test Results |
1000 surges, 6000 Volts, 3000 Amps, B3 pulse |
| Measured suppressed voltage |
170 Volts, no failures |
| Federal Guidelines |
Grade A, Class 1, Mode 1 (CID A-A-55818) |
| Maximum Applied Surge Pulse Joule Rating |
Unlimited, due to current limiting (8 x 20 µs) |
| EMI/RFI Filter, Normal Mode (50-ohm load) |
40 dB @ 100 kHz; 50 dB @ 300 kHz;
50 dB @ 3 MHz; 50 dB @ 30 MHz |
| EMI/RFI Filter, Common Mode (50-ohm load) |
18 dB @ 300 kHz; 30 dB @ 1 MHz;
50 dB @ 5 MHz; 50 dB @ 20 MHz |
| Maximum Applied Surge Voltage |
6000 Volts |
| Maximum Applied Surge Current |
Unlimited, due to current limiting* |
| Endurance (C62.41-1991 Category B3 pulses) |
Unlimited, due to current limiting* |
| Dimensions |
4" H x 10.2" W x 4.2" D (10.2 x 25.9 x 10.7 cm) |
| Weight |
8.5 lbs (3.8 kg) |
| Temperature Range |
5º to 35º C |
| Humidity Range |
5% to 95% R.H., non-condensing |
| Agency Listings |
ETL and cETL certified to (UL 1449; CSA C22.2 No.8-M1986, R2000)
UL 1283 |
| Warranty |
Limited lifetime and limited five (5) years connected protection |
