Sonel LKZ-1000 Wires and Pipe Locator

Name: Sonel LKZ-1000 Wires and Pipe Locator
Brand: Sonel
SKU: SonelLKZ-1000
Price: 2573.00 USD
Availability: InStock

0 reviews | Catalog: WMXXLKZ1000 | UPC: 5907624021044 | Model: Sonel LKZ-1000

Compare

Underground cable locator

Backlit LCD with contrast (auto on-off)
Automatic adjustment of detection sensitivity
5 operating modes
Warning about shallowly located cables
Measuring cable locations up to 3 m deep
Determining the direction of a cable
Sound signals to facilitate locating or tracing
Adjustment of power and selection of frequencies for the transmitter
Passive or active modes of tracing
Detection of underground live wires
Detection of underground wires with no voltage (radio mode)
Detection of underground wires with no voltage using a transmitter (galvanised, inductive or clamp-based connection)
Tracing metallic or non-conductive pipes using an additional probe. tracing non-conductive pipelines using a "floating" probe
Tracing a determined cable
Determining the depth of a cable

View Product Details

List Price: $2,573.00

In Stock:

View Payment Options

Recommended for you

Sonel LKZ-1000 Wires and Pipe Locator

Backlit LCD with contrast (auto on-off)
Automatic adjustment of detection sensitivity
5 operating modes
Warning about shallowly located cables
Measuring cable locations up to 3 m deep

LKZ-1000 with a new transmitterSmaller, more powerful, easier to use!

Improved LKN-1000 transmitter delivers significantly higher power than previous model, which allows to:

Tracking underground services over a, longer distances
Improve service detection in areas of high signal interference
Improve depth estimation

Other benefits of the new transmitter:

Four adjustable output levels with maximum output level, of 1 W
Durable waterproof design environmental protection rating of IP65
Smaller and lighter designed to work in harsh conditions
Choice of 3 tracing signals, 8 kHz or 33 kHz, in conductive mode 8 kHz and 33 kHz at the same time
Clear visual and visual signals for easier operation
In built test function - allowing operators to test the hardware and software functionality of the LKN-1000 before use
Externally located control buttons, ensure a waterproof

Specifications
Electric security
LKN-1000 transmitter's protection class acc. to PN-EN 60529	IP65 (closed cover)
LKO-1000 tracer's protection class acc. to PN-EN 60529	IP54
Other technical data
Transmitter's power supply	4 x batteries LR20
Transmitter's dimensions	180 x 280 x 260 mm
Transmitter's weight	< 2.4 kg
Tracer's maximum range	3 m
Receiver's power supply	6 x battery LR6
Receiver's dimensions	760 x 250 x 85 mm
Receiver's weight	< 2.9 kg
Rated operational conditions
Operating temperature	-20...+50 °C

Underground Utility Locators Template
Depth estimation	Yes
Bluetooth	No
Package with transmitter	Yes
Test Equipment General Attributes
Warranty	3 YEARS
Safety Approval	CE, RoHS
Product Weight	6 LBS
Product Height	10.00 IN
Product Length	6.00 IN
Product Width	12.00 IN
Shipping Weight	8.2 KILOS (18.08 LBS)
ECCN Number	EAR99
Battery Type	AA
Power Supply Voltage	Battery Powered
Country of Origin	United Kingdom
Shipping Height	10.00 IN
Shipping Length	6.00 IN
Shipping Width	12.00 IN
