Simpson M23510230 Digital Panel Meter

Name: Simpson M23510230 Digital Panel Meter
Brand: Simpson
SKU: SimpsonM23510230
Price: 184.72 USD
Availability: InStock

0 reviews | Catalog: M23510230 | Model: Simpson M23510230

Compare

3-1/2 BKLT, 85-250VAC,20MADC

3/64 DIN Indicator
Unique mounting bracket allows stacking of multiple units
Screw terminal connectors for easy installation
LCD: 3-1/2 digit, 0.5" high LCD display with optional negative image, bright red backlighting
Limited range display scaling
85 - 250 ACV DPM Power Supply
20 DCmA Function Range

View Product Details

List Price: $227.35

Your Price: $184.72

Sign-in for EDU Pricing!

In Stock:

View Payment Options

Request Quote

Items in This Series



Product	Simpson M23510230 3-1/2 BKLT, 85-250VAC,20MADC	Simpson M23500830 3-1/2 LCD, 85-250VAC, 20-199.9HZ S	Simpson M23500711 3-1/2 LCD, 85-250VAC, 4-20MADC, 12	Simpson M23512240 3-1/2 BKLT, 9-32VDC, 200MADC	Simpson m235-2-2-11-0 3-1/2 LED 9-32DCV 200 DCmV no output.	Simpson m235-2-2-14-0 4-1/2 digit LED Display 9-32 DCV DPM Power Supply 200DCV function ra ...	Simpson M23500342 3-1/2 LCD, 85-250VAC, 200 ACVTRMS, 24VDC	Simpson M23502142 3-1/2 LCD, 9-32VDC, 200VDC, 24VDC	Simpson M23522342 3-1/2 LED, 9-32VDC, 0-200VAC, 24V	Simpson M23502132 3-1/2 LCD, 9-32VDC, 20VDC, 24VDC
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Simpson’s Mini-Max Indicators provide high quality, accuracy and reliability in a compact, 60mm deep case.

LCD (Liquid Crystal Display) Units oer a 3-1/2 digit, 0.5” (12.7mm) LCD display with an optional bright red, negative image backlight.

All unitsfeature user-selectable decimal point, auto zero and limited scaling capabilities. A unique mounting bracket is provided to allow for vertical or horizontal stacking of multiple indicators. All Mini-Max units feature a 3/64 DIN, high-impact plastic case. The LCD units have a clear viewing window and the LED units have a red viewing window.

DISPLAY
Type	7-segment LCD or LED
Height	LCD 0.5” (12.7mm)
Decimal point	3-position selectable
Overrange indication	LCD Most signicant digit = “1”
LCD Backlighting	Optional negative image, red backlight
Polarity	Auto with “-” indication, “+” implied
POWER REQUIREMENTS
AC Volt	85-250VAC @40-440Hz
DC Volt	9-32VDC
Power Consumption	(Non Fused)
85-250VAC	LCD 4.0VA (2.4W) max
9-32VDC	LCD 3W max
Isolation	250VRMS max
NOISE REJECTION
CMRR	86dB typical
ACCURACY @ 25°C
±(0.1% of reading ± 1 count)
ENVIRONMENTAL
Operating Temperature	0 to 55°C
Storage Temperature	-10 to 60°C
Relative Humidity	0 to 85% non condensing @40°C
Temperature Coecient	(0.2% of reading ±0.5 digits)/°C
Warmup time	Less than 20 minutes
ANALOG TO DIGITAL CONVERSION
Technique	Integrating dual slope
Rate	3 samples/second-typical
MECHANICAL
Bezel	0.95” x 2.84” (24mm x 72mm)
Depth	2.36” (60mm)
Panel cutout	0.88” x 2.68” (22.2 x 68mm)
Weight	LCD 3.5oz (99.2g)
Case Material	94-0,UL-rated ,glass-lled thermoplastic

Tech Specs

Temperature / PID Controllers
Size Rectangular	Other Size Rectangular 3/64 DIN
Panel Meters/Panel Meters Template
Type (Panel Meter )	Digital
Style (Panel Meter)	Rectangular/Square
Number of Inputs (Panel Meters)	Single
Mounting (Panel Meter)	Panel Mount
Input (Panel Meters)	Current
Accuracy	±(0.1% of reading ± 1 count)
Power Supply (Panel)	AC Volts, DC Volts
Test Equipment General Attributes
Unique Features	85 - 250 ACV DPM Power Supply 20 DCmA Function Range
Product Weight	99.2 GRAMS (0.219 LBS)
Country of Origin	United States
Other Information	Bezel:: 0.95” x 2.84” (24mm x 72mm) Depth:: 2.36” (60mm) Panel cutout:: 0.88” x 2.68” (22.2mm x 68mm)
