• 4-1/2 digit, Red LED, 9-36 DCV, 200 DCV, Two 5A Relay
• Easy to understand programming menu
• 16 point scaling linearization
• Screw terminals for easy installation
• 2 Year Warranty

Mounting Requirements

The Hawk 3 Advanced Digital Controller 1/8 DIN meters require a panel cutout of 1.77” (45mm) high by 3.62” (92mm) wide.

To install the Hawk 3 meter into a panel cutout, remove the clips from the side of the meter.

Slide the meter through the panel cutout, then slide the mounting clips back on the meter. Press evenly to ensure a proper fit . Tighten screws

To replace the engineering unit label, place the tip of a ballpoint pen into the small hole at the base of the engineering label in the bezel.

Slide the label up until it pops out. Grasp and remove. Slide the new label half the distance in, then use the ballpoint pen to slide it down into place.
