Simpson G1001310 GIMA Series Three Phase Digital Panel Meter

Name: Simpson G1001310 GIMA Series Three Phase Digital Panel Meter
Brand: Simpson
SKU: SimpsonG1001310
Price: 429.89 USD
Availability: InStock

0 reviews | Catalog: G1001310 | Model: Simpson G1001310

Compare

G100-110VAC, 277/480 VOLT, 5 AMP

Four Model Types Designed to Fit a Wide Range of
Applications
One Meter to Measure all your Values
1/4 DIN (96 x 96 mm Bezel, 92 x 92 mm Cutout) 2.8” (71 mm) Behind Panel
Easy Installation - Software Detection/Correction of
Wiring Errors
Wide Backlit LCD Display for Easy Viweing
Easy to Use - Four Keys Select all Parameters

View Product Details

List Price: $529.10

In Stock:

View Payment Options

Recommended for you

The GIMA® series of digital panel meters measures values by replacing ammeters, voltmeters, switches, Power Factor & kW indicators, kWh meters, etc. The Simpson GIMA® series provides a single source of instrumentation for all measurement and metering requirements. The GIMA® series offers accurate, high-speed, continuous measurements irrespective of harmonics and waveform interruptions. Each GIMA® Series unit can be used as a single-phase or a three-phase meter. These meters feature “Auto-commissioning” to ensure that a reverse current transformer connection will not cause reading errors. Per-Phase kW and Power Factor allow a crossphase connection error to be quickly and easily detected. The GIMA® Series can also be tested at minimal loads. This is possible by the full four-digit resolution of single-phase values and five-digit resolution of three-phase values. The GIMA® series meters offer maximum visibility with a custom backlit LCD display. The display is fully visible under most conditions and from most angles. Clear display legends ensure simple readings with no multipliers required. To provide more value to this series, Simpson is offering a range of accessories such as serial communications, analog outputs and three-phase current transformers. Some of these accessories are retro-fit options. With the addition of these accessories, the GIMA® series is able to fit within most applications.

Ordering Options

Inputs

System

3-phase, 3 or 4-wire unbalanced load

Voltage

120/208, 120//240, 277/480, 63/110
Measurement
Range:0.5% to 120%

Current

5 amp from external CTs Fully Isolated
Measurement
Range:0.5% to 120%

Operating

Frequency

45 to 65 Hz

Harmonics

Up to the 20th harmonic

Input Loading

Voltage

Less than 0.1VA per phase

Current

Less than 0.1VA per phase

Overload

Voltage

x2 for 2 seconds max.

Current

x40 for 1 second max

External Supply

Standard

115V±15% 45-65Hz

Optional

230V±15% 45-65Hz

General

Display

Custom backlit supertwist LCD 3 lines of .47” (12mm) digits plus .15” (3.8mm) legends

Environmental

Temperature

14°F to 149°F (-10°C to 65°C) operating

Humidity

<75% RH non-condensing

Programming

CT Primary

5A to 6500A

VT Primary

60V to 50,000V

Pulse Output

Function

Output 1 Wh (G200, G300 & G400 only)
Output 2 Total varh (G300 & G400 only)
Pulse Length: 100ms
Isolation: 2500V (50 Output 1 to Output 2)
Scaling: Can be set 1, 10 or 100 pulse output rate

Accuracy

	Per Phase	3 Phase
Current 5% to 120%FS	±0.2%FS ±1% Rdg*	N/A
Voltage LN 20% to 120%FS	±0.2%FS ±1% Rdg*	N/A
Voltage LL 20% to 120%FS	±0.3%FS ±1% Rdg*	N/A
Watts 5% to120% FS	±0.4% FS ±1% Rdg	±0.6% FS ±1% Rdg*
VA 5% to120% FS	±0.6% FS ±1.5% Rdg	±1% FS ±1.5% Rdg
VAR 5% to120% FS	±0.8%FS ±2% Rdg	±1.5% FS ±2% Rdg
PF	±0.2°FS	±0.2° FS
Frequency		±0.05 Hz
Neutral Current 5% to 120%FS	N/A	±0.6% FS ±2% Rdg
Wh Register	N/A	Class 1 EN 61036
VAh Register	N/A	Class 2
varh Register	N/A	Class 2 IEC 1268
Note: All accuracies specified are ±1 digit * Rdg = Reading

Temperature / PID Controllers
Size Rectangular	1/4 DIN
Panel Meters/Panel Meters Template
Type (Panel Meter )	Digital
Style (Panel Meter)	Rectangular/Square
Number of Inputs (Panel Meters)	Dual
Mounting (Panel Meter)	Panel Mount
Input (Panel Meters)	Current, Voltage
Size-Face Width	Other
Process Output	No
Control / Alarm Setpoints	No
Water Proof	No
Splash Proof	No
Relay Output	No
Test Equipment General Attributes
Product Height	4.10 IN
Product Length	5.10 IN
Product Width	5.10 IN
Country of Origin	United States
Shipping Height	4.10 IN
Shipping Length	5.10 IN
Shipping Width	5.10 IN
