| DC VOLTAGE |
| Ranges |
250mV, 1 V, 2.5V, 10V, 25V,100V, 250V, 500V, 1000V |
| Accuracy |
2% of full scale |
| Sensitivity |
20K per volt |
| AC VOLTAGE |
| Ranges |
2.5V, 10V, 25V, 100V, 250V,500V, 1000V |
| Accuracy |
3% of full scale |
| Sensitivity |
5K per volt |
| DECIBEL |
| 5 Ranges |
-20 to +39dB |
| Reference |
0dB= 1mW into 600Ω |
| DC CURRENT |
| Ranges |
50μA, 0.5mA, 5mA, 50mA,500mA, 5A |
| Accuracy |
1.0% full scale 50μA2.0% full scale, all other |
| Voltage Drop: (Nominal) |
250 mV on 50μA/0.5mA/5A, 252mV on 5mA/50mA, 400mV on 500mA |
| STANDARD POWER RESISTANCE |
| Ranges |
Rx1, Rx100, Rx1K, Rx10K |
| Accuracy |
2.5° of arc on Rx1, 2.0° of arc all other |
| Maximum Indication |
0-2KΩ, 0-200KΩ, 0-2MΩ, 0-20MΩ |
| Open Circuit Voltage |
1.5V, 1.5V, 1.5V, 9.0V |
| Short Circuit Current |
250mA, 2.5mA, 250μA, 125μA |
| LOW POWER RESISTANCE |
| Ranges |
Rx1, Rx10 |
| Accuracy |
2.5° of arc on Rx1, 2.0° of arc on Rx10 |
| Maximum Indication |
0-1KΩ, 0-10KΩ |
| Open Circuit Voltage |
100mV |
| Short Circuit Current |
4.9mA, 490μA |
| General Specifications |
| Batteries |
1.5V AA, 9V (NEDA No. 13F, 1604A) |
| Fuse |
F1 1A, 250V, Type 3AG, quick acting Littelfuse® Type 312001, F2 2A,600V Littelfuse® Type BLS or 2A 600V, Bussman® Type BBS. |
| Size |
5 1/4" x 7" x 3 1/8" (13.34 x 17.78 x 7.94 cm) |
| Weight |
2 1/4 lbs. (1.02 Kg) |
| Rated Circuit-To-Ground Voltage |
1000V AC/DC Max |
