Simpson 17882 Panel Meter CENT 2173D----0-150 WATTS 3.5

Name: Simpson 17882 Panel Meter CENT 2173D----0-150 WATTS 3.5
Brand: Simpson
SKU: Simpson17882
Price: 481.81 USD
Availability: InStock

0 reviews | Catalog: 17882 | Model: Simpson 17882

Simpson Century Style Analog Panel Meters

Compare

2173D----0-150 WATTS 3.5 CENT

2173D----0-150 WATTS 3.5 CENT
UL Recognized
Glass window for optimum viewing
Rugged black plastic case
Black knife-edge pointer for precision reading

View Product Details

List Price: $566.85

Your Price: $481.81

Sign-in for EDU Pricing!

In Stock:

View Payment Options

Request Quote

Recommended for you

General Specifications
Accuracy	±2% F.S.; Compensated Meters: ±3% F.S.
Movement	Dynamometer
Suspension	Pivot and jewel
Tracking	±3%
Shielding	Calibration is unaffected by magnetic panel mounting
Response Time	1.5 seconds maximum
Overload (1 sec.)	10 times F.S.
Overload (Continuous)	1.5 times F.S.
Repeatability	2%
Dial	Each dial arc is calibrated to track the specific type of movement used
Resistance	±15% of meter impedance
Operating Temperature	-4ºF to +149ºF (-20ºC to +65ºC)
Case	High density black plastic
Pointer	Knife-edge, with black matte finish
Scale Length	Model 2173 2.48” (63.0mm)
Net Weight	Model 2173 9oz (0.26kg)

Tech Specs

Panel Meters/Panel Meters Template
Type (Panel Meter )	Analog
Style (Panel Meter)	Rectangular/Square
Number of Inputs (Panel Meters)	Single
Mounting (Panel Meter)	Panel Mount
Input (Panel Meters)	Other
Size-Circular	2.82 IN
Size-Face Width	3 1/2 in
Process Output	No
Control / Alarm Setpoints	No
Water Proof	No
Splash Proof	No
Relay Output	No
Test Equipment General Attributes
Country of Origin	United States
