Simpson 17672 Panel Meter UL CENT 2152MD---0-30 ACA 2.5

Name: Simpson 17672 Panel Meter UL CENT 2152MD---0-30 ACA 2.5
Brand: Simpson
SKU: Simpson17672
Price: 114.78 USD
Availability: InStock

0 reviews | Catalog: 17672 | Model: Simpson 17672

Simpson Century Style Analog Panel Meters

Compare

2152MD---0-30 ACA 2.5 UL CENT

2152MD---0-30 ACA 2.5 UL CENT
UL Recognized
Glass window for optimum viewing
Rugged black plastic case
Black knife-edge pointer for precision reading

View Product Details

List Price: $135.03

Your Price: $114.78

Sign-in for EDU Pricing!

In Stock:

View Payment Options

Request Quote

Items in This Series



Product	Simpson 17672 2152MD---0-30 ACA 2.5 UL CENT	Simpson 17682 2152MD---0-100 ACMA 2.5 UL CENT	Simpson 17666 2152MD---0-1.5 ACA 2.5 UL CENT	Simpson 17684 2152MD---0-500 ACMA 2.5 UL CENT	Simpson 17681 2152MD---0-50 ACMA 2.5 UL CENT	Simpson 17673 2152MD---0-50 ACA 2.5 UL CENT	Simpson 17683 2152MD---0-250 ACMA 2.5 UL CENT	Simpson 17669 2152MD---0-10 ACA 2.5 UL CENT	Simpson 17670 2152MD---0-15 ACA 2.5 UL CENT	Simpson 17667 2152MD---0-3 ACA 2.5 UL CENT	Simpson 17668 2152MD---0-5 ACA 2.5 UL CENT	Simpson 17674 2152MD---0-100 ACA 2.5 UL CENT	Simpson 17665 2152MD---0-1 ACA 2.5 UL CENT	Simpson 17680 2152MD---0-10 ACMA 2.5 UL CENT	Simpson 17671 2152MD---0-25 ACA 2.5 UL CENT
Price
In Stock
Type (Panel Meter )	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog	Analog
Style (Panel Meter)	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square	Rectangular/Square
Number of Inputs (Panel Meters)	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single	Single
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

General Specifications
Accuracy	±2% F.S. Iron Vane, ±3% F.S. Rectified
Movement	Models 2152, 2153, 2154: Iron-vane, magnetically damped
Suspension	Pivot and jewel except for “T” models which have taut band movement
Tracking	±3%
Shielding	Calibration is unaffected by magnetic panel mounting
Response Time	1.5 seconds maximum
Overload (1 sec.)	10 times F.S.
Overload (Continuous)	1.5 times F.S.
Repeatability	2% pivot and jewel, 0.5% taut band
Dial	Each dial arc is calibrated to track the specific type of movement used
Resistance	±15% of meter impedance
Operating Temperature	-4ºF to +149ºF (-20ºC to +65ºC)
Case	High density black plastic
Pointer	Knife-edge, with black matte finish
Scale Length	Model 2152: 1.86” (47.2mm)
Net Weight	Model 2152: 5oz (0.14kg)

Tech Specs

Panel Meters/Panel Meters Template
Type (Panel Meter )	Analog
Style (Panel Meter)	Rectangular/Square
Number of Inputs (Panel Meters)	Single
Mounting (Panel Meter)	Panel Mount
Input (Panel Meters)	Current
Size-Circular	2.22 IN
Size-Face Width	2 1/2 in
Process Output	No
Control / Alarm Setpoints	No
Water Proof	No
Splash Proof	No
Relay Output	No
Test Equipment General Attributes
Country of Origin	United States
