| DC VOLTAGE |
| Ranges |
250mV, 1V, 2.5V, 10V, 50V, 250V, 500V, 1000V |
| Accuracy |
2% of full scale |
| Sensitivity |
20K per volt |
| AC VOLTAGE |
| Ranges |
2.5V, 10V, 50V, 250V, 500V, 1000V |
| Accuracy |
3% of full scale |
| Sensitivity |
5K /volt |
| DECIBEL |
| 5 Ranges |
-20 to +50dB |
| Reference |
0dB= 1mW into 600Ω |
| DC CURRENT |
| Ranges |
50μA, 1mA, 10mA, 100mA, 250mA, 500mA |
| Accuracy |
2% of full scale |
| Voltage Drop: (Nominal) |
250 mV or 50 mV on 50μA, (2ranges) 50 mV, all others |
| RESISTANCE |
| Ranges |
Rx1, Rx10, Rx100, Rx1K, Rx10K |
| Accuracy |
3° of arc |
| Maximum Indication |
0-3K, 0-30K, 0-300K, 0-3M, 0-30M |
| General Specifications |
| Batteries |
1.5V AA, 22.5V (Neda No.13F, Eveready 505) |
| Operating Temperature Range |
75°F for rated accuracy; less than 4% additional error over the range of +25°F to +130°F |
| Size |
4-9/16" x 3-5/16" x 1-3/4" (11.59 x 8.41 x 4.45 cm). |
| Weight |
Approximately 12 ounces (.34 Kg) |
| Construction |
Combination high impact plastic and phenolic case |
| Rated Circuit-To-Ground Voltage |
1000V AC/DC Max. |
