Simpson 00290 Model 27A Style - Rectangular 0-15 DCA 3.5 UL RECT.

For industrial or commercial applications, the Rectangular style panel meter offers maximum reliability and ±2% full scale (F.S.) accuracy. With a black phenolic case and glass window for optimum viewing, the Rectangular style meter is a popular replacement. DC units are available in either the standard pivot and jewel or taut band suspen- sion which provides optimum band length for shock pro- tection. The self-shielded meter movement prevents mag- netic interaction between the meter and a steel panel. Three popular sizes of 2-1/2", 3-1/2", and 4-1/2" are avail- able to measure varying current ranges. This style meter is ideal for many other electrical functions. See the “Function Reference Table.”

Function Reference Table

For your convenience, the table below lists Rectangular models for other electri- cal monitoring functions with page number reference.


Function	Section	Page
AC Current	E	19
AC Voltage	E	39
DC Voltage	E	79
Watts	E	111
