SDG6022X - Pulse/Arbitrary Waveform Generator (2 Channels/200 MHz/2.4 GSa/s)

SIGLENT's SDG6000X is a series of dual-channel Pulse/ Arbitrary Waveform Generators that feature up to 500 MHz bandwidth, a maximum sample rate of 2.4 GSa/s, and 16-bit vertical resolution. They also include proprietary TrueArb and EasyPulse technology that help solve the weaknesses inherent in traditional DDS generators when generating arbitrary, square, and pulse waveforms.

In addition, the SDG6000X is a multi-function device that can generate Noise, IQ signals, and PRBS patterns. These features enable the SDG6000X to provide a variety of high fidelity and low jitter signals, meeting the growing requirements of complex and intensive applications.

• 2 channels / 200 MHz bandwidth
• 2.4 GSa/s maximum sampling rate
• 16-bit vertical resolution
• 20 Mpts waveform length
• EasyPulse circuit lowers jitter and increases pulsed performance

Siglent’s SPD3000X Series Programmable Linear DC Power Supply has a 4.3” TFT-LCD display, supports Remote Programming, and has a Real-Time Wave Display. The SPD3000X has three isolated outputs; two adjustable channels and one selectable channel from 2.5 V, 3.3 V, and 5 V. It also has work short and overload protection and can be used in production and development.

• Programmable linear DC power supply
• Three independently controlled and isolated outputs
• Resolution: 1 mV, 1 mA
• Display with 5-digit voltage and 4-digit current
• Channels 1 and 2 are adjustable, channel 3 has fixed selections

Siglent SDL1000X/E programmable DC electronic loads feature a 3.5-inch TFT-LCD display, a user-friendly interface, and superb performance specifications. The series delivers stability over various applications and can meet many testing requirements, including battery and handheld device design, LED lighting, automotive electronics, aerospace, and more.

• Single-channel, programmable DC electronic load
• Input: 150V/30A/300W
• Minimum readback resolution: 0.1mV/0.1mA
• 4 static modes / Dynamic mode: CC/CV/CR/CP
• CC Dynamic mode: Continuous, pulsed, toggled

• Maximum differential test voltage: 1500V (DC + Peak AC)
• Bandwidth: 100 MHz
• Attenuation: 50x / 500x
• Accuracy: +/- 2%
• Standard USB power adapter 5V/1A

16 digital channels (software).

The Siglent SPL2016 adds 16-channel digital input capability to Siglent SDS2000X, SDS2000XP, and SDS5000X oscilloscopes.

Waveform generator (software)

Power Analysis (software)

The Siglent DF2001A is a power analysis deskew fixture. It is designed for use with voltage and current probes, along with the power analysis option on 4 channel units in the SDS2000X, SDS2000X Plus, and SDS5000X oscilloscope series.

• Bandwidth: DC-100MHz
• Rise time: ≤ 3.5ns
• Continuous max input range: 30Arms
• Max peak current value: 50Apk

The Siglent SRF5030T near field probe set is the magnetic field (H) and electric field (E) probes for radiated emissions EMC pre-compliance measurements. The probes are used in the near field of sources of electromagnetic radiation and serve to locate and identify potential sources of interference within the building blocks of electronic assemblies.
