Seaward 293A910 Europa Plus PATSolutions Kit

Name: Seaward 293A910 Europa Plus PATSolutions Kit
Brand: Seaward
SKU: Seaward293A910
Availability: InStock

0 reviews | Catalog: 293A910 | Model: Seaward 293A910

Compare

Seaward 293A910

Europa Plus PATSolutions kit :

Europa Plus advanced portable PAT tester with in-situ earth bond and touch current tests
PATGuard Elite 2 software for easy PAT data management
PATGuard support contract
Test 'n' Tag portable label printer
Connectors
Barcode scanner
Carry case
Calibration certificate
Seaward Guide to PAT testing

View Product Details

In Stock:

Recommended for you

Choose a Category

(0)

In Stock!

Add to Cart

Technical Specification
Earth Continuity
Test Currents	25A AC, 10A AC, 4A AC +200mA DC
Display Range	0.01ohms - 19.99ohms
Pass Value	User Defined
Measurement Technique	4 wire measurement, floating earth
Earth Screen Continuity
Test Current:	100mA
Display Range:	0.00ohms - 19.99ohms
Pass Value:	User Defined
Measurement Technique:	4 wire measurement, floating earth
Insulation Resistance
Test Voltage:	250V, 500V DC
Display Range:	0.1Mohms - 100Mohms
Pass Value:	User Defined
Protective Conductor Current
Test Voltage:	230V
Display Range:	0.1mA - 10mA
Pass Value:	User Defined
Touch Current
Test Voltage:	230V
Display Range:	0.1mA - 2.0mA
Pass Value:	User Defined
Substitute Leakage
Test Voltage:	40V AC Nominal
Display Range:	0.1mA - 19.99mA
Pass Value:	User Defined
Load Test
Display Range:	0kVA - 4.2kVA
IEC Lead Polarity
Tests Performed:	Live/Neutral Continuity and Polarity
Operating Voltage
Voltage Range:	207V - 253V 45Hz - 65Hz
Weight / Dimensions
Weight and Dimensions:	3.5Kg / 31cm x 21cm x 8cm
Interfaces
Keyboard:	QWERTY
Display Graphic:	LCD - 1/4 VGA (320x240 pixels)
Connectivity:	2 serial port connections
