Scienscope CMO-LE-W10 E-Series Eyepieces (10X) - Pair

Name: Scienscope CMO-LE-W10 E-Series Eyepieces (10X) - Pair
Brand: Scienscope
SKU: ScienscopeCMO-LE-W10
Price: 131.40 USD
Availability: InStock

0 reviews | Model: Scienscope CMO-LE-W10

Compare

10X eyepiece (pair) for E-Series

10X Eyepieces (Pair)

View Product Details

List Price: $146.00

In Stock:

View Payment Options

Recommended for you

General Specifications
Eyepiece:	Wide Field 10X eyepieces (pair) with Eyecups [eyepieces housing of 30mm diameter]

SZ Binocular Optical Specifications

Objective Lens	Eyepieces								Working Distance
	10X		15X		20X		25X
	MAG	FOV (mm)	MAG	FOV (mm)	MAG	FOV (mm)	MAG	FOV (mm)
0.3X	2x-13.5x	109.5-16.3	3x-20.3	79.6-11.9	4x-27x	59.7-8.9	5.0x-33.8x	44.8-6.7	287mm
0.4X	2.7x-18x	82.1-12.2	4x-27x	59.7-8.9	5.4x-36x	44.8-6.7	6.7x-45.0x	33.6-5	217mm
0.5X	3.4x-22.5x	65.7-9.8	5x-33.8x	47.8-7.1	6.7x-45x	35.8-5.3	8.4x-56.3x	26.9-4	177mm
0.75X	5x-33.8x	43.8-6.5	7.5x-50.6x	31.8-4.7	10.1x-67.5x	23.9-3.6	12.6x-84.4x	17.9-2.7	117mm
1X	6.7x-45x	32.8-4.9	10.1x-67.5x	23.9-3.6	13.4x-90x	17.9-2.7	16.8x-112.5x	13.4-2	100mm
1.5X	10.1x-67.5x	21.9-3.3	15.1x-101.3x	15.9-2.4	20.1x-135x	11.9-1.8	25.1x-168.8x	9-1.3	47mm
2X	13.4x-90x	16.4-2.4	20.1x-135x	11.9-1.8	26.8x-180x	9-1.3	33.5x-225x	6.7-1	26mm

ELZ Binocular Optical Specifications

Objective Lens	Eyepieces						Working Distance
	10X		15X		20X
	MAG	FOV (mm)	MAG	FOV (mm)	MAG	FOV (mm)
0.5X	3.5x-15x	66.9-15	5.3x-22.5x	4.6-11	7x-30x	36-8.3	177mm
1X	7x-30x	31.4-7.3	10.5x-45x	22.9-5.3	14x-60x	17.9-4.1	100mm
2X	14x-60x	16-3.7	21x-90x	11.4-8	28x-120x	9-6	26mm

SZ Trinocular Video Specifications

Objective Lens	Video Couplers						Working Distance
	0.35X		0.5X		1X
	MAG	FOV (mm)	MAG	FOV (mm)	MAG	FOV (mm)
0.3X	3.6x-24x	100-13	6x-40x	60-8.6	12x-81x	30-4.3	287mm
0.4X	4.8x-32x	75-10	8x-54x	45-6.5	16x-108x	22.5-3.25	217mm
0.5X	6x-40x	60-8	10x-68x	36-5.2	20x-135x	18-2.6	177mm
0.75X	9x-61x	40-5.3	15x-101x	24-3.5	30x-203x	12-1.8	117mm
1X	12x-81x	30-4	20x-135x	18-2.6	40x-270x	9-1.3	100mm
1.5X	18x-122x	20-2.6	30x-203x	12-1.8	60x-405x	6-0.9	47mm
2X	24x-162x	15-2	40x-270x	9-1.3	80x-540x	4.5-0.65	26mm
