General Specifications |
Image Sensor |
1/1.8? Interline CCD (ICX274AQ) |
Signal Format |
Color Progressive |
Operating Systems |
Windows 2000, XP, Vista (32 bit) & Linux |
Drivers |
Viewing Software (Simple & Advanced Menus), DirectX, Twain, Linux, NI LabVIEW |
Software Development Kit |
Standard SDK & Trigger SDK (for Software and Hardware Triggers) - Full Documentation |
Maximum Frame Rate |
- Full Scan |
15 fps |
- 1/2 Partial Scan |
30 fps |
- 1/4 Partial Scan |
60 fps |
Total Picture Element |
1688 (H) x 1248 (V) |
Effective Picture Element |
- Full |
1600 (H) x 1200 (V) |
- 1/2 Partial |
1600 (H) x 544 (V) |
- 1/4 Partial |
1600 (H) x 208 (V) |
Chip Size (mm) |
8.50 (H) x 6.80 (V) |
Cell Size (um) |
4.40 (H) x 4.40 (V) |
Pixel Clock Frequency |
36.818 MHz |
Trigger Method |
Software Trigger (Edge Preset) |
Scanning Method |
Full Progressive, Partial Scanning (1/1, 1/2, 1/4) |
Sync System |
Internal Sync |
Internal Sync |
Progressive |
Shutter Speed |
Auto / Fixed (Software Selectable, Values Set via Software) |
Minimum Illumination |
0.73 Lux @ F1.2, 20 IRE, 1.39 Lux @ F1.2, 50 IR |
Minimum Illumination |
0.73 Lux @ F1.2, 20 IRE, 1.39 Lux @ F1.2, 50 IRE |
Ext. Low Light Capability |
Extended Low Light Capability via Software Trigger |
Gain |
Extended Low Light Capability via Software Trigger |
Gamma |
Analog & Digital Gains (Able to be set independently) |
Lens Mount |
C Mount |
White Balance |
Auto / Manual / One-shot |
Video Output |
USB 2.0 High Speed |
Shock |
70G (3 Directions, 3 Times Each) |
Vibration |
10G (20 to 200Hz) |
Power |
2.80W, < 560mA |
Input Voltage |
+5V through USB port |
Operating Temperature |
0?C ~ 40?C (32F? ~ 104?F) |
Storage Temperature |
-30?C ~ 65?C (-22?F ~ 149?F) |
Dimensions |
51 (W) x 51 (H) x 44.3 (D) mm (2" x 2" x 1.74") |
Weight |
Approximately 145g (5.11oz.) |
