| General Specification |
| IP rating |
IP 65, dust and water ingress protection testing standard |
| Radio approvals |
Europe (CE), USA (FCC), Canada (IC) |
| CE mark |
CE approved |
| Velocity |
10 Hz to 1 kHz up to 2.17 in/s (55mm/s)
Recommended speed range: 600 rpm - 3600 rpm |
| Bearing condition |
SKF patented envelope acceleration up to 20 gE |
| Maximum frequency |
Velocity 1 kHz, enveloped acceleration 2 kHz |
| Lines of resolution |
Velocity 400, enveloped acceleration 800 |
| Detection type |
Velocity RMS, enveloped acceleration true peak to peak |
| Temperature |
Capable of measuring outwith standard temperatures range up to 212°F (100°C) for short periods |
| Main power |
Rechargeable lithium battery, 3.7 V DC, 0.14 A |
| Battery lifetime |
Eight hours with normal usage
Manual power off: Press and hold
power button for 3+ seconds
Auto power off: After 15 minutes of no activity |
| MAINS supply |
Varies up to ±10% of the nominal |
| voltage, charger |
voltage, TRANSIENT OVERVOLTAGE CATEGORY II; POLLUTION DEGREE 2 |
| Charger |
Input 5 V DC ±10%, 1 A |
| AC adapter |
Input 100 to 240 V DC, 0.4 A, 47 to 63 Hz
Output 5 V DC, 1.6 A |
| Storage temperature |
-5 to +115 °F (-20 to +45 °C) for less than one month
-5 to +95 °F (-20 to +35 °C) for less than six months |
| Operating temperature |
32 to +105 °F (0 to +40 °C) for charging battery
-5 to +140 °F (-20 to +60 °C) for discharging |
| Operating temperature |
32 to +105 °F (0 to +40 °C) charger |
| Altitude |
Up to 6,560 ft (2,000 m) |
| Humidity |
95% non-condensing |
| Case |
Water and dust resistant (IP65) |
| Drop test |
6 ft (1.8 m) in accordance with MIL-STD-810G |
| Dimensions |
1.8 x 1.8 x 5.3 in (45 x 45 x 135 mm) |
| Weight |
7 oz (200 g) |
