| DIN 51825 code |
KP2G-20 |
| NLGI consistency class |
2 |
| Soap type |
Lithium |
| Colour |
Light brown |
| Base oil type |
Mineral |
| Operating temperature range |
–20 to +110 °C (–5 to +230 °F) |
| Dropping point DIN ISO 2176 |
>180 °C (>355 °F) |
| Base oil viscosity (40 °C, mm²/s) |
200 |
| Base oil viscosity (100 °C, mm²/s) |
16 |
| Penetration DIN ISO 2137 (60 strokes, 10–1 mm) |
265–295 |
| Penetration DIN ISO 2137 (100 000 strokes, 10–1 mm) |
+50 max. (325 max.) |
| Mechanical stability (Roll stability, 50 hrs at 80 °C, 10–1 mm) |
+50 max. |
| Mechanical stability (V2F test) |
'M' |
| Corrosion protection (Emcor: – standard ISO 11007) |
0–0 |
| Corrosion protection (Emcor: – water washout test) |
0–0 |
| Corrosion protection (Emcor: – salt water test (100% seawater)) |
1–1* |
| Water resistance (DIN 51 807/1, 3 hrs at 90 °C) |
1 max. |
| Oil separation (DIN 51 817, 7 days at 40 °C, static, %) |
2–5 |
| Lubrication ability (R2F, running test B at 120 °C) |
Pass |
| Copper corrosion (DIN 51 811, 110 °C) |
2 max. |
| EP performance (Wear scar DIN 51350/5, 1 400 N, mm) |
1,4 max |
| EP performance (4–ball test, welding load DIN 51350/4, N) |
2 800 min. |
| Fretting corrosion (ASTM D4170 (mg)) |
5,7* |
