Skf Cmss 2200F-33 -Condition Monitoring

Name: Skf Cmss 2200F-33 -Condition Monitoring
Brand: SKF
SKU: SKFCMSS 2200F-33
Price: 785.10 USD
Availability: InStock

0 reviews | UPC: 7316576188480 | Model: SKF CMSS 2200F-33

Compare

CONDITION MONITORING

For use with all SKF on-line systems, protection systems, the portable data collection instruments
Economical, top exit design
Rugged, corrosion resistant and hermetically sealed
Case isolation
Meets stringent CE, EMC requirements
ESD protection
Reverse wiring protection

View Product Details

List Price: $1,592.78

In Stock:

Recommended for you

The CMSS 2100F accelerometer is a good multi-purpose sensor with integral cable for light to medium-duty applications in the following industries:

Food and Beverage - common applications include general purpose machines such as pumps, motors and fans.

Dynamic
Sensitivity	100 mV/g
Sensitivity precision	±5% at 25 °C (75 °F)
Acceleration range	80 g peak
Amplitude linearity	1%
Frequency range	±10%: 1,0 to 8 000 Hz, ±3 dB: 0,5 to 13 000 Hz
Resonance frequency, mounted, nominal	30 kHz
Transverse sensitivity	≤ 5% of axial
Temperature response	See graph
Electrical
Power requirements	Voltage source1: 18 to 30 V DC, Constant current diode1: 2 to 10 mA
Electrical noise	Broadband: 2,5 Hz to 25 kHz: 700 µg, Spectral: 10 Hz: 10 µg/√Hz, 100 Hz: 5 µg/√Hz, 1 000 Hz: 5 µg/√Hz
Output impedance	< 100 Ω
Bias output voltage	12 V DC
Grounding	Case isolated, internally shielded
Environmental
Temperature range	–50 to +120 °C (–60 to +250 °F) operating temperature
Vibration limit	500 g peak
Shock limit	5 000 g peak
Electromagnetic sensitivity, equivalent g maximum	70 µg/gauss
Sealing	Hermetic
Base strain sensitivity	0,0002 g/µstrain
Hydrostatic pressure	100 psi
CE	According to the generic immunity standard for Industrial Environment EN 50082-2
Physical
Weight	90 g (3.2 oz.)
Case material	316L stainless steel
Mounting	Internal 1/4-28 thread
Mounting torque	2,9 Nm (24 in. lbs.)
Connections	Power/Signal: White, Common: Black, Case: Shield
Integral cable	Fluorine-based polymer, 10 meter (33 feet) blunt cut

Test Equipment General Attributes
Product Weight	90 GRAMS (0.198 LBS)
Product Height	1.00 IN
Product Length	10.00 IN
Product Width	10.00 IN
Shipping Height	1.00 IN
Shipping Length	10.00 IN
Shipping Width	10.00 IN
