| Rohde & Schwarz RTO6-K22 Specifications |
| Supported Ethernet compliance tests |
| Standard reference |
|
IEEE 802.3-2012 |
| 1000BASE-T |
with/without disturber |
with/without TX_CLK transmitter distortion (40.6.1.2.4) |
| peak differential output voltage (40.6.1.2.1) |
| maximum output droop (40.6.1.2.2) |
| differential output templates (40.6.1.2.3) |
| with TX_CLK |
jitter master mode (40.6.1.2.5), jitter slave mode (40.6.1.2.5) |
| without TX_CLK |
jitter master mode (40.6.1.2.5) |
| common |
MDI return loss (40.8.3.1), common-mode output voltage (40.8.3.3) |
| 100BASE-TX |
|
amplitude domain tests (9.1.2.2, 9.1.3 and 9.1.4) |
| rise and fall times (9.1.6) |
| peak to peak duty cycle distortion (9.1.8) |
| peak to peak transmitter jitter (9.1.9) |
| active output interface template (annex J) |
| transmitter return loss (9.1.5) |
| receiver return loss (9.2.2) |
| 10BASE-T |
no TPM |
link test pulse template (14.3.1.2.1) |
| TP_IDL template (14.3.1.2.1) |
| peak differential voltage (14.3.1.2.1) |
| harmonic content (14.3.1.2.1) |
| output timing jitter (14.3.1.2.3) |
| with TPM |
link test pulse template (14.3.1.2.1) |
| TP_IDL template (14.3.1.2.1) |
| MAU template (14.3.1.2.1) |
| output timing jitter (14.3.1.2.3) |
| common |
transmitter return loss (14.3.1.2.2), receiver return loss (14.3.1.3.4) |
| common-mode output voltage (14.3.1.2.5) |
| Supported EEE compliance tests |
| Standard reference |
|
IEEE 802.3-2012 |
1000BASE-T EEE
(requires R&S ® RT-ZF5) |
|
quiet time (78.2) |
| refresh time (master) (78.2) |
| refresh time (slave) (78.2) |
| wake state levels (40.6.1.2.7) |
| transmitter timing jitter with TX_TCLK (master) (40.6.1.2.5) |
| transmitter timing jitter with TX_TCLK (slave) (40.6.1.2.5) |
| transmitter timing jitter without TX_TCLK (master) (40.6.1.2.5) |
| transmitter timing jitter without TX_TCLK (master) (40.6.1.2.5) |
100BASE-TX EEE
(requires R&S ® RT-ZF5) |
|
sleep time (24.2.3.4 and 78.2) |
| LPI quiet time (24.2.3.4 and 78.2) |
| LPI refresh time (24.2.3.4 and 78.2) |
| LPI transmitter timing jitter (24.2.3.4 and 78.2) |
| transmit wake time (24.2.3.4 and 78.2) |
| 10BASE-Te (requires R&S ® RT-ZF4) |
no TPM |
link test pulse template (14.3.1.2.1) |
| TP_IDL template (14.3.1.2.1) |
| peak differential voltage (14.3.1.2.1) |
| harmonic content (14.3.1.2.1) |
| output timing jitter (14.3.1.2.3) |
| with TPM |
link test pulse template (14.3.1.2.1) |
| TP_IDL template (14.3.1.2.1) |
| MAU template (14.3.1.2.1) |
| output timing jitter (14.3.1.2.3) |
| common |
transmitter return loss (14.3.1.2.2), receiver return loss (14.3.1.3.4) |
| common-mode output voltage (14.3.1.2.5) |
