| Rohde & Schwarz RTO6-K133 Specifications |
| Jitter separation |
total jitter (TJ),
deterministic jitter (DJ),
data dependent jitter (DDJ),
periodic jitter (PJ),
data dependent jitter plus periodic jitter (DDJ+PJ),
random jitter (RJ),
(other) bounded uncorrelated jitter ((O)BUJ),
random jitter plus (other) bounded uncorrelated jitter (RJ+(O)BUJ) |
| Accepted input signals |
clock signals or data signals (NRZ) |
| Reference clock |
internal clock recovery (PLL first or second order, constant clock or feed forward) or explicit clock signal |
| Basic measurements |
symbol rate, symbol duration, event count |
| Jitter measurements |
total jitter at bit error rate (TJ@BER) |
value in seconds or unit interval BER value selectable between 10-32 and 10-1 |
| deterministic jitter (DJ, dual-dirac) |
value in seconds or unit interval |
| duty cycle distortion (DCD) |
value in seconds or unit interval |
| inter symbol interference (ISI) |
value in seconds or unit interval |
| total jitter (TJ) corresponds to time interval error (TIE) |
peak-to-peak value and RMS value in seconds or unit interval |
| deterministic jitter (DJ) |
peak-to-peak value and RMS value in seconds or unit interval |
| data dependent jitter (DDJ) |
peak-to-peak value and RMS value in seconds or unit interval |
| periodic jitter (PJ) |
peak-to-peak value and RMS value in seconds or unit interval |
| data dependent jitter plus periodic jitter (DDJ+PJ) |
peak-to-peak value and RMS value in seconds or unit interval |
| periodic jitter components |
amplitude, frequency, direction (vertical or horizontal) |
| random jitter (RJ) |
RMS value in seconds or unit interval |
| (other) bounded uncorrelated jitter ((O)BUJ), |
peak-to-peak value and RMS value in seconds or unit interval |
| (other) bounded uncorrelated jitter ((O)BUJ, dual-dirac), |
value in seconds or unit interval |
| random jitter plus (other) bounded uncorrelated jitter (RJ+(O)BUJ) |
peak-to-peak value and RMS value in seconds or unit interval |
| Statistics |
max. and min. values for each jitter measurement type |
| Jitter result plots |
histogram (rising edges only) |
TJ, DJ, DDJ, PJ, RJ+OBUJ |
| histogram (falling edges only) |
TJ, DJ, DDJ, PJ, RJ+OBUJ |
| histogram (both edges) |
TJ, DJ, DDJ, PJ, RJ+OBUJ |
| TIE track |
TJ, DDJ, PJ, RJ+OBUJ |
| power spectral density (PSD) |
TJ, DDJ, PJ, RJ+OBUJ |
| Additional result plots |
step response |
| bathtub |
PJ and (O)BUJ removable from noise bathtub |
| synthetic eye diagram |
DD only, DD+P(h), DD+P(v), DD+P |
