Rohde and Schwarz RTO-K2 - UART/RS232/422/485 Triggering and Decoding (Catalog 1329.7277.02)

Name: Rohde and Schwarz RTO-K2 - UART/RS232/422/485 Triggering and Decoding (Catalog 1329.7277.02)
Brand: Rohde & Schwarz
SKU: Rohde & SchwarzRTO-K2
Price: 2755.00 USD
Availability: InStock

0 reviews | Catalog: 1329.7277.02 | Model: Rohde & Schwarz RTO-K2

Rohde & Schwarz RTO-K2 - UART/RS232/422/485 triggering and decoding (Catalog 1329.7277.02)

Compare

RS-232/UART serial triggering and decoding (for models 1329.7002.xx) (software license)

Catalog number 1329.7277.02
For use with RTO2000 series oscilloscopes
Serial standard: UART/ RS-232/ RS-422/ RS-485
Includes decode tables, trigger, label support, search
Trigger on start, break, data and various error conditions
Telegram display as color-coded bus signals and in decode table
Supports decoding of up to 4 serial buses from analog or digital channel signals
On-screen serial decoding is time-correlated with the serial data waveform

View Product Details

Your Price: $2,755.00

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
Request a Demo

View Payment Options

Request Quote

Recommended for you

Rohde and Schwarz RTO-K2 - UART/RS232/422/485 Triggering and Decoding (Catalog 1329.7277.02)

Catalog number 1329.7277.02
For use with RTO2000 series oscilloscopes
Serial standard: UART/ RS-232/ RS-422/ RS-485
Includes decode tables, trigger, label support, search
Trigger on start, break, data and various error conditions

All Rohde & Schwarz oscilloscopes support triggering and decoding of UART and of RS-232, RS-422 and RS-485 buses. You can set up decoding in seconds. For detailed analysis, results can be viewed as color-coded telegrams and/or in a table. Errors are identified efficiently and reliably using the hardware-accelerated trigger. You can trigger on start, break, data and various error conditions.

Bus decoding selection with the app cockpit

Bus setup in seconds with the app cockpit

Starting from the app cockpit, it only takes a few steps to configure any given protocol. Once the bus to decode has been chosen, the connected channels selected and the correct levels set, decoding begins automatically.

Decoded frames are color-coded

Telegram display as color-coded bus signals and in decode table

You can analyze the decoded bus frames by overlaying the signal with color-coded data. Address and data content can be displayed in hex, bin or ASCII format. You always have the best overview with the flexible screen setup. The telegrams can also be displayed in a concise table.

Protocol trigger setup dialog

Strong trigger capability on start, stop, address, data and various error conditions

The protocol-specific trigger lets you reliably isolate protocol events and errors. Thanks to high acquisition rates, Rohde & Schwarz oscilloscopes are ideal for finding errors quickly, allowing decoding of protocol-specific trigger results. The hardware-based triggering is available on specific protocol content, e.g. addresses, data and protocol errors.
