Rohde and Schwarz RTB-B6 - Waveform and Pattern Generator Option for RTB2000 Oscilloscopes

Name: Rohde and Schwarz RTB-B6 - Waveform and Pattern Generator Option for RTB2000 Oscilloscopes
Brand: Rohde & Schwarz
SKU: Rohde & SchwarzRTB-B6
Price: 670.00 USD
Availability: InStock
Rating: 4.00 (1 reviews)

4 (1 Review) | Catalog: 1333.1111.02 | Model: Rohde & Schwarz RTB-B6

Compare

Waveform generator (via software key)

Waveform and pattern generator option for RTB2000 oscilloscopes
Activated via software keycode

View Product Details

Your Price: $670.00

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
Request a Demo

View Payment Options

Request Quote

Items in This Series


Product	Rohde & Schwarz RTB-B6 Waveform generator (via software key)	Rohde & Schwarz RTB-B1 Mixed signal option (Hardware and software license)	Rohde & Schwarz RTB-K1 I2C/SPI serial triggering and decoding (via software key)	Rohde & Schwarz RTB-K2 UART/RS232 serial triggering and decoding option (via software key)	Rohde & Schwarz RTB-K3 CAN/LIN serial triggering and decoding option (via software key)	Rohde & Schwarz RTB-K15 History and segmented memory option (via software key)	Rohde & Schwarz RTB-K36 Bode Plot Analysis Range: Up to 25 MHz Source: Internal Generator ...
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Rohde and Schwarz RTB-B6 - Waveform and Pattern Generator Option for RTB2000 Oscilloscopes

Waveform and pattern generator option for RTB2000 oscilloscopes
Activated via software keycode

The following is an overview of available software options for Rohde and Schwarz RTB2000 oscilloscopes.

RTB-B1 - Mixed signal
RTB-B6 - Waveform generator
RTB-K1 - I2C / SPI serial triggering and decoding
RTB-K2 - UART / RS232 serial triggering and decoding
RTB-K3 - CAN / LIN serial triggering and decoding
RTB-K15 - History and segmented memory
RTB-PK1 - Application bundle, includes the following:
- I2C/SPI (R&S RTB-K1)
- UART/RS232 (R&S RTB-K2)
- CAN/LIN (R&S RTB-K3)
- History and segmented memory (R&S RTB-K15)
- Waveform generator (R&S RTB-B6)

RTB-B6 Specifications
Waveform generator and 4-bit pattern generator
Waveform generator
Resolution		14-bit
Sample rate		250 Msample/s
Amplitude	Level
	high Z	20 mV to 5 V (Vpp)
	50 Ω	10 mV to 2.5 V (Vpp)
	accuracy	3 %
DC offset	Level
	high Z	±2.5 V
	50 Ω	±1.25 V
	accuracy	3 % or ± 5 mV whatever is greater
Sine	frequency	0.1 Hz to 25 MHz
	SFDR	> 40 dBc (meas.)
	THD	> 40 dBc (meas.)
Pulse/rectangle	frequency	0.1 Hz to 10 MHz
Ramp/triangle	frequency	0.1 Hz to 1 MHz
Arbitrary	sample rate	max. 10 Msample/s
Arbitrary	memory depth	16k points
Noise	bandwidth	max. 25 MHz
Noise	level	0 % to 100 % of signal amplitude
Modulation	AM
	function	sine, rectangle, triangle, ramp
	frequency	0.1 Hz to 1 MHz
	depth	0 % to 100 %
	FM
	function	sine, rectangle, triangle, ramp
	frequency	0.1 Hz to 1 MHz
	deviation	depends on modulation frequency
	ASK
	function	sine, rectangle, triangle, ramp
	frequency	0.1 Hz to 1 MHz
	ASK depth	0 % to 100 %
	FSK
	function	sine, rectangle, triangle, ramp
	frequency	0.1 Hz to 1 MHz
	FSK rate	0.1 Hz to carrier frequency/2
Sweep	start frequency	1 Hz to 25 MHz
	stop frequency	1 Hz to 25 MHz
	sweep time	1 ms to 10 s
	sweep type	linear, logarithmic, triangle
4-bit pattern generator
Functions		probe adjust/square wave, bus signal source 4-bit counter, programmable 4-bit pattern
Probe adjust		1 kHz/1 MHz square wave signal approx. 2.5 V (Vpp) (tr < 4 ns)
Bus signal source		SPI, I2C, UART
Bus signal source	bandwidth	9600 bit/s to 1 Mbit/s
4-bit counter	frequency	1 mHz to 25 MHz
Programmable pattern	sample rate	20 ns to 1 s, up/down
	memory depth	2048 bit
	pattern idle time	50 ns to 1 s
