| MIL-STD-1553 triggering and decoding |
| Protocol configuration |
source |
| R&S RTA4004 |
channel 1, channel 2, channel 3, channel 4, logic channels from D15 to D0 (with R&S RTA-B1 option) |
| bit rate |
standard bit rate (1 Mbit/s) |
| polarity |
normal, inverted |
| label list |
associate frame identifier with symbolic ID |
| auto threshold setup |
assisted threshold configuration |
| timing |
max response (4 µs to 200 µs) |
| Trigger |
trigger event setup |
sync, word, command word, status word, command and data word, error condition |
| sync setup |
all words, command/status word, data word |
| word setup |
all words, command word, status word, data word |
| command word setup (type: address/word) |
RT address (condition =, ≠, ≥, ≤, in range, out of range); direction (T/R); subaddress (condition =, ≠, ≥, ≤, in range, out of range); data word count (condition =, ≠, ≥, ≤, in range, out of range) |
| command word setup (type: mode code) |
RT address (condition =, ≠, ≥, ≤, in range, out of range); subaddress (0, 31 or either); mode code from labeled dropdown list |
| status word setup |
RT address; status flags (message error, instrumentation, service request, broadcast command, busy, subsystem flag, dynamic bus control, terminal flag) individually configurable (1, 0, don’t care) |
| command and data word setup |
transmission type (BC-RT, RT-BC, BCBC, mode code); RT address (condition =, ≠, ≥, ≤, in range, out of range); subaddress (condition =, ≠, ≥, ≤, in range, out of range); data word count (condition =, ≠, ≥, ≤, in range, out of range); data pattern up to 4 words long (condition =, ≠, ≥, ≤, in range, out of range); payload data index (condition =) |
| error condition setup |
any combination of sync error, Manchester error, parity error, timing error (see protocol configuration) |
| Decode |
display signals |
bus signal; symbolic ID in bus signal when label list in use |
| color coding |
sync, RT address, subaddress, mode code, status bit field, data, error condition |
| displayed format of data |
hex, decimal, binary, ASCII |
| frame table |
decode results displayed as tabulated list, errors highlighted in red; frame navigation; data export as CSV file; column with symbolic ID when label list in use |
| Search |
search events |
word, command word, mode code, status word, command and data word, error |
| word setup |
command, status, data |
| command word setup |
see trigger settings for “command word setup (type: address/word)” |
| mode code setup |
see trigger settings for “command word setup (type: mode code)” |
| status word setup |
see trigger settings for “status word setup” |
| command and data word setup |
see trigger settings for “command and data word setup” |
| error condition setup |
all, sync, parity, manchester, timing |
