| Memory Depth | 1M points (Single Channel), 512K points (Dual Channels) |
| Channels | Dual Channels + External Trigger |
| Real-time Sample Rate | 400 MSa/s |
| Equivalent Sample Rate | 25 GSa/s |
| Rise Time | 5.8ns |
| Time Base Range | 5 ns/div to 50 s/div |
| Trigger Modes | Edge, Video, Pulse Width, Slope, Alternative |
| Trigger Sources | CH1, CH2, Ext, Ext/5, AC Line |
| Input Impedance | 1 MΩ || 15 pF |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Vertical Resolution | 8 bits |
| Input Coupling | DC, AC, Ground |
| Maximum Input Voltage | 400 V (DC + AC peak) |
| Roll Range | 500 ms/div to 50 s/div |
| Automatic Measurements | Vpp, Vamp, Vmax, Vmin, Vtop, Vbase, Vavg, Vrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall time, Positive Width, Negative Width, Positive Duty Cycle, Negative Duty Cycle, Delay 1→2 , Delay 1→2 |
| Cursor Measurements | Manual, Track and Auto Measure modes. |
| Math | Add, Subtract, Multiply, FFT |
| Storage | Internal - 10 Waveforms and Setups / USB - BMP, CSV, Waveforms and Setups |
| I/O | USB Device, USB Host, RS-232, P/F Out (Isolated) |
| Display | TFT (64K, Color LCD), 320 x 234 |
| Power | Worldwide Use, 100 ? 240 V / 50 VA Max |
| Weight | 2.3 kg |
