| Frequency Range |
| Model RSA3015E/RSA3015E-TG |
9 kHz to 1.5 GHz |
| Model RSA3030E/RSA3030E-TG |
9 kHz to 3 GHz |
| Internal Reference Frequency |
| Reference Frequency |
10 MHz |
| Accuracy |
±[(time since last calibration × aging rate) + temperature stability + calibration accuracy] |
| Initial Calibration Accuracy |
Standard |
<1 ppm |
| Option OCXO-C08 |
<0.1 ppm |
| Temperature Stability |
|
0 °C to 50 °C, with the reference 25 °C |
| Standard |
<0.5 ppm |
| Option OCXO-C08 |
<0.005 ppm |
| Aging Rate |
Standard |
<1 ppm/year |
| Option OCXO-C08 |
<0.03 ppm/year |
| Displayed Average Noise Level (DANL) |
| |
attenuation = 0 dB, sample detector, trace averages ≥ 50, tracking generator off, normalized to 1 Hz, 20 °C to 30 °C, input impedance = 50 Ω. |
| Preamp off |
9 kHz to 100 kHz |
<-120 dBm (typical) |
| 100 kHz to 20 MHz |
<-135 dBm, <-140 dBm (typical) |
| 20 MHz to 1.5 GHz |
<-138 dBm, <-141 dBm (typical) |
| 1.5 GHz to 3.0 GHz |
<-136 dBm, <-141 dBm (typical) |
| Preamp on |
100 kHz to 20 MHz |
<-152 dBm, <-160 dBm (typical) |
| 20 MHz to 1.5 GHz |
<-158 dBm, <-161 dBm (typical) |
| 1.5 GHz to 3.0 GHz |
<-156 dBm, <-161 dBm (typical) |
| SSB Phase Noise |
| |
20 °C to 30 °C，fc = 500 MHz |
| Carrier Offset |
1 kHz |
<-90 dBc/Hz (typical) |
| 10 kHz |
<-100 dBc/Hz, <-102 dBc/Hz (typical) |
| 100 kHz |
<-100 dBc/Hz, <-102 dBc/Hz (typical) |
| 1 MHz |
<-110 dBc/Hz, <-112 dBc/Hz (typical) |
