Specifications are valid under the following conditions: the instrument is within the calibration period, is stored for at least two hours at 0ºC to 50ºC temperature, and is warmed up for 40 minutes. Unless otherwise noted, the specifications in this manual include the measurement uncertainty.
Typical (typ.): characteristic performance, which 80 percent of the measurement results will meet at room temperature (approximately 25ºC ). This data is not warranted and does not include the measurement uncertainty.
Nominal (nom.): the expected mean or average performance or a designed attribute (such as the 50 Ω connector). This data is not warranted and is measured at room temperature (approximately 25ºC ).
Measured (meas.): an attribute measured during the design phase which can be compared to the expected performance, such as the amplitude drift variation with time. This data is not warranted and is measured at room temperature (approximately 25ºC ). NOTE: All charts in this manual are the measurement results of multiple instruments at room temperature unless otherwise noted. The specifications (except the TG specifications) listed in this manual are those when the tracking generator is off. |
| Frequency |
| Model |
DSA815
DSA815-TG (with preamplifier and tracking generator) |
DSA832 |
DSA875 |
| Frequency range |
9 kHz to 1.5 GHz |
9 kHz to 3.2 GHz |
9 kHz to 7.5 GHz |
| Frequency range |
1 Hz |
| Reference frequency |
10MHz |
| Accuracy |
±[(time since last adjustment × aging rate)+temperature stability + calibration accuracy] |
| Initial calibration accuracy |
<1ppm |
| Initial calibration accuracy |
0ºC to 50ºC , reference to 25ºC |
| < 2ppm |
< 0.5ppm |
| Aging rate |
< 2ppm/year |
< 1ppm/year |
| Marker resolution |
span/ (number of sweep points - 1) |
| Marker uncertainty |
±(frequency indication × frequency reference uncertainty + 1% × span + 10% × resolution bandwidth + marker resolution) |
| Resolution |
1 Hz, 10 Hz, 100 Hz, 1 kHz, 10kHz, 100kHz |
| Uncertainty |
±(frequency indication × reference frequency accuracy + counter resolution) |
| Range |
0Hz, 100Hz to maximum frequency of instrument |
| Uncertainty |
±span/ (number of sweep points - 1) |
| |
20ºC to 30ºC , f c =1 GHz |
| Carrier offset |
DSA815 |
DSA832 |
DSA875 |
| 10 kHz |
<-80 dBc/Hz |
<-98 dBc/Hz |
![1]() |
![2]() |
| |
20ºC to 30ºC , RBW = VBW = 1 kHz |
| |
DSA815 |
DSA832 |
DSA875 |
| Residual FM |
< 50 Hz (nom.) |
< 20Hz (nom.) |
| |
DSA815 |
DSA832 |
DSA875 |
| Resolution bandwidth (-3dB) |
100 Hz to 1 MHz, in 1-3-10 sequence |
10 Hz to 1 MHz, in 1-3-10 sequence |
| RBW uncertainty |
<5% (nom.) |
Resolution filter shape factor
(60dB: 3dB) |
<5 (nom.) |
| Video bandwidth (-3dB) |
1 Hz to 3 MHz, in 1-3-10 sequence |
Resolution bandwidth (-6dB)
(EMI-DSA800 option) |
200 Hz, 9 kHz, 120 kHz |
| Amplitude |
| Range |
f c ≥10MHz |
| DANL to +20 dBm |
| DC voltage |
50 V |
| CW RF power |
attenuation = 30 dB |
| +20 dBm (100 mW) |
| Max. damage level [1] |
+30 dBm (1 W) |
| NOTE: [1] When f c ≥ 10 MHz, input level > +25 dBm and PA is Off, the protection switch will be on. |
![3]() |
![4]() |
| |
DSA815 |
| Frequency |
attenuation = 0 dB, RBW = VBW = 100 Hz, sample detector, trace average ≥ 50, tracking generator off, 20ºC to 30ºC , input impendence = 50 Ω |
| PA off |
100 kHz to 1 MHz |
<-90 dBm, <-110 dBm (typ.) |
| 1MHz to 1.5 GHz |
<-110 dBm+6×(f/1GHz)dB, <-115 dBm (typ.) |
| PA on |
100 kHz to 1 MHz |
<-110 dBm, <-130 dBm (typ.) |
| 1MHz to 1.5 GHz |
<-130 dBm+6×(f/1GHz)dB, <-135 dBm (typ.) |
| |
DSA832 |
DSA875 |
| Frequency |
attenuation = 0 dB, RBW = VBW = 10 Hz, sample detector, trace average ≥ 50, tracking generator off, 20ºC to 30ºC , input impendence = 50 Ω |
| PA off |
9 kHz to 100 kHz |
<-110 dBm (typ.) |
<-110 dBm (typ.) |
| 100 kHz to 5 MHz |
<-125 dBm, <-128 dBm (typ.) |
<-125 dBm, <-128 dBm (typ.) |
| 5 MHz to 3.2 GHz |
<-130 dBm, <-134 dBm (typ.) |
<-130 dBm, <-134 dBm (typ.) |
| 3.2 GHz to 6 GHz |
|
<-126 dBm, <-130 dBm (typ.) |
| 6 GHz to 7.5 GHz |
|
<-121 dBm, <-125 dBm (typ.) |
| PA on |
100 kHz to 5 MHz |
<-142 dBm, <-145 dBm (typ.) |
<-142 dBm, <-145 dBm (typ.) |
| 5 MHz to 3.2 GHz |
<-147 dBm, <-151 dBm (typ.) |
<-147 dBm, <-151 dBm (typ.) |
| 3.2 GHz to 6 GHz |
|
<-143 dBm, <-147 dBm (typ.) |
| 6 GHz to 7.5 GHz |
|
<-138 dBm, <-142 dBm (typ.) |
| |
DSA815 |
DSA832 |
DSA875 |
| Frequency |
attenuation = 0 dB, RBW = VBW = 100 Hz, sample detector, trace average ≥ 50, tracking
generator off, normalized to 1Hz, 20ºC to 30ºC , input impendence = 50 Ω |
| PA off |
| 9 kHz to 100 kHz |
|
<-120 dBm (typ.) |
<-120 dBm (typ.) |
| 100 kHz to 1 MHz |
<-110 dBm,
<-130 dBm (typ.) |
<-135 dBm,
<-138 dBm (typ.) |
<-135 dBm,
<-138 dBm (typ.) |
| 1MHz to 5MHz |
<-130 dBm+6×(f/1GHz)
dB,
<-135 dBm (typ.) |
| 5 MHz to 1.5 GHz |
<-140 dBm,
<-144 dBm (typ.) |
<-140 dBm,
<-144 dBm (typ.) |
| 1.5 GHz to 3.2 GHz |
|
| 3.2 GHz to 6 GHz |
|
|
<-136 dBm,
<-140 dBm (typ.) |
| 6 GHz to 7.5 GHz |
|
|
<-131 dBm,
<-135 dBm (typ.) |
| PA on |
| 100 kHz to 1 MHz |
<-130 dBm,
<-150 dBm (typ.) |
<-152 dBm,
<-155 dBm (typ.) |
<-152 dBm,
<-155 dBm (typ.) |
| 1MHz to 5MHz |
<-150dBm + 6×
(f/1GHz)dB,
<-155 dBm (typ.) |
| 5 MHz to 1.5 GHz |
<-157 dBm,
<-161 dBm (typ.) |
<-157 dBm,
<-161 dBm (typ.) |
| 1.5 GHz to 3.2 GHz |
|
| 3.2 GHz to 6 GHz |
|
|
<-153 dBm,
<-157 dBm (typ.) |
| 6 GHz to 7.5 GHz |
|
|
<-148 dBm,
<-152 dBm (typ.) |
![5]() |
![6]() |
| Logarithmic level axis |
1 dB to 200 dB |
| Linear level axis |
0 to Reference Level |
| Number of display points |
601 |
| Number of traces |
3 + Math Trace |
| Trace detectors |
normal, positive-peak, negative-peak, sample, RMS, voltage average |
| quasi-peak (with EMI-DSA800 option) |
| Trace functions |
clear write, max hold, min hold, average, view, blank |
| Units of level axis |
dBm,dBmV, dBμV, nV, μV, mV, V, nW, μW, mW, W |
| |
DSA815 |
DSA832 |
DSA875 |
| Frequency response |
f c ≥100kHz, attenuation = 10 dB, relative to 50 MHz, 20ºC to 30 ºC |
| PA off |
| 100kHz to 1.5GHz |
<0.7 dB |
<0.5 dB, <0.3 dB(typ.) |
| 1.5GHz to 3.2GHz |
|
| 3.2GHz to 7.5GHz |
|
<0.7 dB, <0.3 dB(typ.) |
| |
f c ≥1MHz, attenuation = 10 dB, relative to 50 MHz, 20ºC to 30 ºC |
| PA on |
| 100kHz to 1.5GHz |
<1.0 dB |
<0.7 dB, <0.3 dB(typ.) |
| 1.5GHz to 3.2GHz |
|
| 3.2GHz to 7.5GHz |
<1.0 dB |
<0.9 dB, <0.3 dB(typ.) |
![7]() |
![8]() |
| |
DSA815 |
DSA832 |
DSA875 |
| Setting range |
0 to 30 dB, in 1 dB step |
| Switching uncertainty |
f c =50 MHz, relative to 10 dB, 20 ºC to 30 ºC |
| < 0.5 dB |
< 0.3 dB |
| |
DSA815 |
DSA832 |
DSA875 |
| Uncertainty |
fc = 50 MHz, peak detector, preamplifier off, attenuation = 10 dB, input signal level = -10 dBm,
20 ºC to 30 ºC |
| <0.4dB |
<0.3 dB |
| Uncertainty |
relative to 1 kHz RBW |
| <0.1 dB |
| Range |
-100 dBm to +20 dBm, in 1 dB step |
| Resolution log Scale |
0.01 dB |
| Resolution linear Scale |
4 digits |
| |
DSA815 (standard) |
PA-DSA832 (option) |
PA-DSA875 (option) |
| Gain |
| 100kHz to 1.5 GHz |
20 dB(nom.) |
17 dB(nom.) |
17 dB(nom.) |
| 1.5GHz to 3.2 GHz |
|
| 3.2GHz to 7.5 GHz |
|
|
| |
DSA815 |
DSA832 |
DSA875 |
| |
95% confidence level, S/N > 20 dB, RBW = VBW = 1 kHz,
preamplifier off, attenuation = 10 dB, -50 dBm < input level ≤ 0 dBm, fc > 10 MHz, 20 ºC to 30 ºC |
| Level measurement uncertainty |
<1.5 dB(nom.) |
<0.8 dB (nom.) |
![10]() |
![11]() |
| |
DSA815 |
DSA832 |
DSA875 |
| attenuation ≥ 10 dB |
| VSWR |
| 300kHz to 1.5GHz |
<1.5(nom.) |
<1.5(nom.) |
<1.5(nom.) |
| 1.5GHz to 3.2GHz |
|
| 3.2GHz to 7.5GHz |
|
|
<1.8(nom.) |
![12]() |
![13]() |
| Distortion |
| |
DSA815 |
DSA832 |
DSA875 |
| Second harmonic Intercept (SHI) |
f c ≥ 50 MHz, input signal level = -20 dBm, attenuation = 10 dB |
| +40dBm |
+45dBm |
| |
DSA815 |
DSA832 |
DSA875 |
Third-order intercept
(TOI) |
f c ≥ 50 MHz, two -20dBm tones at input mixer spaced by 200kHz, attenuation = 10 dB |
| +10dBm |
+11 dBm, +15 dBm (typ.) |
1dB compression of input mixer
(P 1dB ) |
fc ≥ 50 MHz, attenuation = 0 dB |
| >0dBm |
![14]() |
![15]() |
| Spurious response |
DSA815 |
DSA832 |
DSA875 |
| input terminated 50 Ω, attenuation = 0 dB, 20ºC to 30ºC |
| < -88dBm (typ.) |
< -90dBm,
< -100dBm (typ.) |
| Intermediate frequency |
< -60 dBc |
| System related sidebands |
referenced to local oscillators, referenced to A/D conversion, referenced to subharmonic of first LO, referenced to harmonic of first LO |
| < -60 dBc |
| Input Related Spurious |
mixer level = -30 dBm |
| < -60 dBc |
| Sweep |
| |
DSA815 |
DSA832 |
DSA875 |
| Sweep time |
| Span≥100 Hz |
10ms to 1500s |
1ms to 1500s |
1ms to 1500s |
| zero span |
20 μs to 1500 s |
20 μs to 3200 s |
20 μs to 7500 s |
| Sweep time uncertainty |
| zero span (sweep time setting value > 1 ms) |
5%(nom.) |
| Sweep mode |
continuous, single |
| Tracking Generator (Option) |
| |
DSA815 |
DSA832 |
DSA875 |
| Frequency range |
100 kHz to 1.5 GHz |
100 kHz to 3.2 GHz |
100 kHz to 7.5 GHz |
| Output level range |
-20 dBm to 0 dBm |
-40 dBm to 0 dBm |
| Output level resolution |
1 dB |
| Output flatness |
relative to 50 MHz |
| ±3 dB (nom.) |
![16]() |
![17]() |
| Trigger Functions |
| Trigger source |
Free run, video, external |
| External trigger level |
5 V TTL level |
| Input /Output |
| RF input |
impedance |
50 Ω (nom.) |
| connector |
N female |
| Tracking generator output |
impedance |
50 Ω (nom.) |
| connector |
N female |
| Internal reference |
frequency |
10 MHz |
| output level |
+3 dBm to +10 dBm, +8 dBm (typ.) |
| impedance |
50Ω (nom.) |
| connector |
BNC female |
| External reference |
frequency |
10 MHz±5 ppm |
| output level |
0 dBm to +10 dBm |
| impedance |
50Ω (nom.) |
| connector |
BNC female |
| External trigger input |
impedance |
1 kΩ (nom.) |
| connector |
BNC female |
| USB host |
connector |
A plug |
| protocol |
Version2.0 |
| USB device |
connector |
B plug |
| protocol |
Version2.0 |
| LAN |
LXI core 2011 device |
10/100Base, RJ-45 |
| IEC/IEEE(GPIB) bus(USB-GPIB option) |
IEEE488.2 |
| General Specifications |
| Type |
TFT LCD |
| Resolution |
800 x 480 pixels |
| Size |
8 inch |
| Colors |
64 k |
| Protocol |
PictBridge |
| Mass Memory |
Flash Disk (internal), USB Disk (not supplied) |
| Input Voltage Range, AC |
100 V to 240 V (nom.) |
| AC Supply Frequency |
45 Hz to 440 Hz |
| Power Consumption |
35 W (typ.),max. 50 W with all options |
| Temperature |
Operating temperature range |
0ºC to 50ºC |
| Storage temperature range |
-20ºC to 70ºC |
| Humidity |
0ºC to 30ºC |
≤95% rel. humidity |
| 30ºC to 40ºC |
≤75% rel. humidity |
| Altitude |
operating height |
up to 3,000m |
| EMC |
In line with EN61326-1:2006 |
| IEC 61000-4-2:2001 |
±4.0kV (contact discharge), ±4.0kV (air discharge) |
| IEC 61000-4-3:2002 |
3V/m (80MHz to 1GHz)
3V/m (1.4GHz to 2GHz)
1V/m (2.0GHz to 2.7GHz) |
| IEC 61000-4-4:2004 |
1kV power lines |
| IEC 61000-4-5:2001 |
0.5kV (Phase to Neutral)
0.5kV (Phase to PE)
1kV (Neutral to PE) |
| IEC 61000-4-6:2003 |
3V,0.15-80MHz |
| IEC 61000-4-11:2004 |
Voltage dip:
0% UT during half cycle
0% UT during 1 cycle
70% UT during 25 cycles
Short interruption:0% UT during 250 cycles |
| Electrical Safety |
In line with
UL 61010-1:2012, CAN/CSA-C22.2 No. 61010-1-12, EN 61010-1:2010 |
| (W x H x D) |
361.6 mm × 178.8 mm × 128 mm
(14.2 in × 7.0 in × 5.0 in) |
| |
DSA815 |
DSA832 |
DSA875 |
| Standard |
4.25 kg (9.4 lb) |
4.55 kg (10.0 lb) |
| With tracking generator |
5.15 kg (11.4 lb) |
