Multifunctional Software
Terminal software facilitates processes such as weighing, parts counting, dosing, labeling, formulations and percent weighing. Terminal’s information system is based on databases (such as users, products, weighings, packaging, formulations, and customers) and ALIBI memory which guarantees stored data safety.
When developing the software, special attention was given to the functionality and ergonomics. This resulted in increased comfort of terminal operation.
Battery as an Optional Power Source
Use of the optional battery enables the PUE HX7 terminal to operate even when there is either no or unstable power supply. This improves the security of acquired data and improves comfort of operation.
Communication Interfaces
The terminal is equipped with RS 322, RS 485, USB, Ethernet, digital inputs/outputs and analog output. This enables connection with external devices such as barcode scanners, printers, external displays, control buttons, light signaling towers, other controlling/signaling devices, systems for automatic process control and superior IT systems. The connection is possible due to the implemented and complex character-based communication protocol. In the future, the interfaces will be extended with Profibus and Profinet. Additionally, Modbus RTU and TCP protocols will be implemented.
Functions
Dosing, percent weighing, parts counting, formulation, replaceable unit, ALIBi memory.
