| General Specifications |
| Operating temperature, F/C |
-13 to 122 / -25 to 50 |
| Windage & Elevation, 1 click (h/v), mm@100m |
34/34 |
| Battery life, (with video out off), hours |
8 |
| Battery Type |
B-Pack (18650 Li-ion) |
| Power Supply |
3-4.2 |
| Range of Detection, yd / m (Object (Human = 1.7*0.5m) |
900 |
| Diopter Adjustment |
+4 to -4 |
| Eye Relief, mm |
50 |
| Distance, Minimum Focusing Distance |
5 |
| Number of Preloaded Reticles |
13 |
| Number of Preloaded Reticles |
13 |
| Height (in/mm) |
2.6/67 |
| Width (in/mm) |
2.8/72 |
| Length (in/mm) |
11.3/287 |
| Weight (without batteries) oz |
16.9 |
| Mounting Brackets on Weapon |
Weaver, Weaver Quick-release, CZ Quick-release |
| Shockresistance, on Rifled Weapon, J |
6000 J |
| Calibration |
Manual, automatic, and semi-automatic |
| Waterproof |
Yes |
| Field of View, m@100m, horizontal |
21.8/16.3 (4x Zoom) |
| Field of View, °, horizontal * vertical |
12.4/9.3 (4x Zoom) |
| Operating modes |
Rocks, forest, identification |
| Video IN / OUT Availability |
Yes |
| Display Resolution, pix. |
640x480 |
| Display Type |
AMOLED |
| Pixel Pitch, µm |
17 |
| Spectral Sensitivity, µm |
8-14 |
| Microbolometer Resolution, pixels |
384x288 |
| Frame Rate |
50 |
| Microbolometer Type |
Uncooled Microbolometer |
| Defective Pixel Repair Option |
Yes |
| Defective Pixel Repair Option |
Yes |
| Magnification |
1.6 |
| Stream Vision support |
Yes |
| Integrated Wi-Fi |
Yes |
| Optical Characteristic, Smooth digital zoom, x |
1.6-6.4 |
| Digital Zoom |
2x/4x |
| Diameter, Lens, mm |
21 |
| Lens Focus, mm |
30 |
| Relative aperture, D/f' |
1:1.6 |
| Model |
XQ30 |
| Objective Lens |
F30/1.6 |
| Microbolometer, resolution |
384x288@17 pixels@pixel pitch, µm |
| Frame Rate |
50 Hz |
| Magnification |
1.6...6.4 x |
| Field of View |
12.4x9.3 horizontal & vertical without zoom, deg |
| Range of Detection |
985 yds |
| Dimensions |
11.3 x 2.8 x 2.6 in |
| Level of Protection (acc. to IEC 60529) |
IPX7 |
| Material, Lens |
Germanium, glass |
| Body Material |
Glass-nylon composite |
| Type of Mount for Attachment of Additional Accessories |
Weaver/Picatinny |
| Optical Characteristic, Reticle, Type |
Variable electronic reticles |
| External Power Supply |
5V-Micro USB |
