Powerside VAT2-600 - Voltage Attenuator Module

Name: Powerside VAT2-600 - Voltage Attenuator Module
Brand: Powerside
SKU: PSVAT2-600
Price: 595.00 USD
Availability: InStock

0 reviews | Catalog: VAT2-600-XXXX | Model: Powerside VAT2-600

Compare

Plug-in 3-phase AC/DC voltage attenuator for PQube3

Upgrade your PQube 3/3e into a dual voltage / dual power analyzer
Connects directly to voltages up to 600 Vac (no external PT required)
Synchronous sampling of all channels up to 512 samples/cycle
Converts 0-600Vac 4-wire (Wye), 3-wire (Delta) or single phase to levels compatible with PQube 3 current input terminals
Outstanding voltage accuracy and frequency response (DC 3 kHz up to the 50th harmonic)

View Product Details

Your Price: $595.00

In Stock:

View Payment Options

Request Quote

Items in This Series



Product	Powerside VAT2-600 Plug-in 3-phase AC/DC voltage attenuator for PQube3	Powerside CTI-1A Plug-in Connect PQube3 to external 1 amp current transformer	Powerside CTI-5A Plug-in Connect PQube3 to external 5 amp current transformer	Powerside VAT2-Cable VAT2 module connection cable for PQube 3 analog channels.	Powerside RM8 Plug-in 8-programmable relay extension module for PQube 3 or PQube 3e	Powerside ATT1-600V Voltage Attenuator Module for PQube 3, 600VDC	Powerside ATT1-1200V Voltage Attenuator Module for PQube 3, 1200VDC	Powerside ATT2-600V Three Phase AC/Dual DC Voltage Attenuator, +/- 600VDC	Powerside ATT2-1200V Three Phase AC/Dual DC Voltage Attenuator, +/- 1200VDC
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Powerside VAT2-600 - Voltage Attenuator Module

Upgrade your PQube 3/3e into a dual voltage / dual power analyzer
Connects directly to voltages up to 600 Vac (no external PT required)
Synchronous sampling of all channels up to 512 samples/cycle
Converts 0-600Vac 4-wire (Wye), 3-wire (Delta) or single phase to levels compatible with PQube 3 current input terminals
Outstanding voltage accuracy and frequency response (DC 3 kHz up to the 50th harmonic)

VAT2-600 Voltage Attenuator Module for PQube 3, 3e

The VAT2-600 attenuator module easily plugs into the PQube 3, and PQube 3e. Transform your power analyzer into a dual voltage / dual power analyzer. It is ideal for monitoring of input and output voltages of UPS, voltage regulators, transformers, and other voltage mitigation equipment.

Note: VAT2-600 can also be used as a DC voltage attenuator.

Powerside VAT2-600 Specifications
Measurement Connections
Voltage In	V1, V2, V3, V4
Input voltage range	0 Vac - 600 Vac L-N or L-L (Nominal) 0 Vac - 707Vac L-N or L-L (Full Scale) ± 1000 Vdc
Voltage configurations	Single-phase (up to 3 single phase voltages with a common neutral) 3-phase 4-wire (Wye/star) or 3-wire (Delta)
Input impedance	4.8 MΩ to Earth
Voltage Out	Va, Vb, Vc, Vd
Output voltage range	0 Vac - 7.07 Vac (Differential outputs to current terminals, single ended outputs to analog terminals)±10 Vdc
Attenuation ratio	100:1
Technical Data
Dimensions (L x W x H)	4.21 in. X 1.64 in. X 2.38 in. (metric: 10.7 cm X 4.17 cm X 6.05 cm)
Installation	DIN rail mountable
Accuracy (±% rdg ±%FS)	±0.1%
Frequency bandwidth	DC - 3 kHz
Harmonic response	±1%
Overvoltage category	CAT IV at 300 Vac, CAT III at 600 Vac
