Pomona 6107 SOIC Clip, 32 pin

Name: Pomona 6107 SOIC Clip, 32 pin
Brand: Pomona
SKU: Pomona6107
Price: 91.40 USD
Availability: InStock

0 reviews | UPC: 095969136624 | Model: Pomona 6107

Compare

32 PIN SOIC TEST CLIP-Note:Price is for 2 Units

Upper contacts are .025" ((0,63)sq. pins on 0.100" (2,54) centers. Pins are perfect for sq. pin receptacles, wire-wrap or soldered wires.
Gold plated upper contacts fit standard double row ribbon cable connectors.
Gold plated lower contacts assure reliable, noise free connections.
Molded barriers between each contact allow connections to be made on live boards without accidental shorting to adjacent chip leads.
Open back of clip allows probing of chip leads while the clip is attached.
Fits all 32 pin surface mounted SOIC and SOJ chips from .30" (7,62) to .60" (15,24) wide.
Compact design requires a minimum of board space. Clips can be placed on chips that are spaced only .040" (1,02) apart, end-to-end. The clip requires .14" (3,56) beyond each side of the chip for placement.
