Pomona 5803A Monolithic Passive Oscilloscope Probe

Name: Pomona 5803A Monolithic Passive Oscilloscope Probe
Brand: Pomona
SKU: Pomona5803A
Price: 68.56 USD
Availability: InStock

0 reviews | UPC: 095969162104 | Model: Pomona 5803A

Compare

OSCILLOSCOPE PROBE

Pomona’s latest design of Passive Oscilloscope probes feature a one piece (monolithic) design for robust probe life.
Probe bandwidth ratings are specified as a system bandwidth. System bandwidth includes both probe and oscilloscope together as a system. The result is a probe frequency response that can essentially can be considered transparent.
For ease of use, Readout Actuator for probe attenuation sensing and a Ground Reference switch are featured on some probe models.
Full set a accessories are included with each probe.
All probes meet IEC1010-2-031, 300V, CAT I

View Product Details

List Price: $74.99

In Stock:

View Payment Options

Recommended for you

Attenuation	X10
System Bandwidth (3dB) MHz.	200
System Risetime ns	1.75
Compensation Range (pf.)	10-60
Voltage Max.	300
Input Res. (MΩ)	10
Input Cap. (pf.)	10
Readout Actuator Pin	No
Gnd. Ref.	No

1.) Measurements based on 1M Ohm, 20 pf. Oscilloscope.
2.) Maximum probe input voltage is limited to the lesser of 300VDC (includes AC peak to 1.3MHz.) or on X1, to the driven equipment’s input rating.

Tech Specs

Test Equipment General Attributes
Product Height	0.85 IN
Product Length	6.55 IN
Product Width	4.80 IN
Country of Origin	United States
Shipping Height	0.85 IN
Shipping Length	6.55 IN
Shipping Width	4.80 IN
