Pomona 4601-2 General Accessories

Name: Pomona 4601-2 General Accessories
Brand: Pomona
SKU: Pomona4601-2
Price: 27.30 USD
Availability: InStock

0 reviews | UPC: 095969173629 | Model: Pomona 4601-2

Compare

TRIPLE BANANA JACK (RED)-Note:Price is for 5 Units

Closed entry receptacle, 4.2 (.166) dia. x 23.4 (.920) deep.
Mounts in panels from 1.6 (.063) to 9.5 (.375) thick.
Nickel plated lock washer and ¼-32 hex nut.
Mates to Model #2970.
Ideal for connection to power supplies with positive, negative and return connections.

View Product Details

List Price: $29.85

In Stock:

Recommended for you

Materials
Banana jack insulation	Polycarbonate molded to banana jack bodies.
Color	One Red, one Black, and one Green.
Mounting Plate	Polycarbonate.
Color	See ordering instructions.
Insulator	Polycarbonate. Color matches color of banana jack insulation.
Lockwasher ¼ Int tooth
Material	Steel.
Finish	Nickel plated per QQ-N-290
Hex nut ¼-32
Material	Brass.
Finish	Nickel plated per QQ-N-290.
Banana jack body/solder turret
Material	Brass, per QQ-B-626, Alloy 360, ½ Hard.
Finish	Bright tin plated per MIL-T-10727.
Ratings
Operating Temperature	+115°C. (+239°F.) Max.
Voltage
Hand-held testing	30VAC/60VDC Max.
Hands free testing in controlled voltage environments	2500 WVDC Max.
Current	15 Amperes
