Pomona 5830-0 - Maxigrabber® Test Clip With Banana Jack And Screw For Direct Wire Attachment, Black

Name: Pomona 5830-0 - Maxigrabber® Test Clip With Banana Jack And Screw For Direct Wire Attachment, Black
Brand: Pomona
SKU: Pomona5830-0
Price: 17.47 USD
Availability: InStock

0 reviews | UPC: 095969162210 | Model: Pomona 5830-0

Compare

FLEXIBLE CLIP (BLACK)

Mates to Model #1440, 4702 and most standard banana plugs
Use set screw to build custom cable with Pomona “Do It Yourself” products
Accepts 18 to 22 AWG wire (for custom cable).
This flexible clip has a rotating pincer type contact to make access easier
Standard banana jack and screw for direct wire termination.
Color - Black

View Product Details

List Price: $17.99

Your Price: $17.47

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Recommended for you

Pomona 5830-0

Mates to Model #1440, 4702, and most standard banana plugs
Use a set screw to build a custom cable with Pomona “Do It Yourself” products
Accepts 18 to 22 AWG wires (for custom cable).
This flexible clip has a rotating pincer-type contact to make access easier.
Standard banana jack and screw for direct wire termination.

Maxigrabber® Test Clip With Banana Jack And Screw For Direct Wire Attachment, Black

Pomona 5830-0 is a Maxigrabber® Test Clip With Banana Jack And Screw For Direct Wire Attachment. Color - Black.

Materials
Wire	Steel.
Insulation	Thermoplastic (handle and knob)
Color	Black (heat shrink tube)
Ratings
Environmental
Operating Temperature	+80°C. (+176°F.) Max.
Electrical
Operating Voltage	300 VRMS/DC
Current	5 Amperes
Mechanical
Grip	Up to .157 (4.0).
