• Passive Oscilloscope probes feature a one-piece (monolithic) design for robust probe life.
• Probe bandwidth ratings are specified as a system bandwidth. System bandwidth includes both probe and oscilloscope together as a system. The result is a probe frequency response that can essentially be considered transparent.
• For ease of use, a Readout Actuator for probe attenuation sensing and a Ground Reference switch is featured on some probe models.
• A full set of accessories is included with each probe.
• All probes meets IEC1010-2-031, 300V, CAT I

Pomona 5800A/POM is a Monolithic Passive Oscilloscope Probe, Upto Cubic 30 Mhz System Bandwidth, Without Compensation Range and Readout Actuator.

Probe Ratio - 1:1

Maximum Input Voltage CAT I - 300

System Bandwidth MHz(-3 dB) - Up to 30

System Risetime(ns) - < 11.66

Probe Input Resistance(M Ohms) - 1

Probe Input Capacitance(pF) - < 57 + O-Scope

Compensation Range(pF) - NA

Readout Actuator - No

Cable Length(meters) - 1.2
