Pomona 4601-0 - Insulated Triple Banana Jack, .75" Spacing

Name: Pomona 4601-0 - Insulated Triple Banana Jack, .75" Spacing
Brand: Pomona
SKU: Pomona4601-0
Price: 8.73 USD
Availability: InStock

0 reviews | UPC: 095969173612 | Model: Pomona 4601-0

Compare

Insulated Triple Banana Jack, .75" Spacing, Black

Closed entry receptacle, 4.2 (.166) dia. x 23.4 (.920) deep.
Mounts in panels from 1.6 (.063) to 9.5 (.375) thick
Nickel plated lock washer and ¼-32 hex nut
Mates to Model #2970.
Ideal for connection to power supplies with positive, negative and return connections.
Color - Black

View Product Details

List Price: $8.99

Your Price: $8.73

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Recommended for you

Pomona 4601-0

Closed entry receptacle, 4.2 (.166) dia. x 23.4 (.920) deep.
Mounts in panels from 1.6 (.063) to 9.5 (.375) thick
Nickel plated lock washer and ¼-32 hex nut
Mates to Model #2970.
Ideal for connection to power supplies with positive, negative and return connections.

Insulated Triple Banana Jack, .75" Spacing, Black

Pomona 4601-0 is an Insulated Triple Banana Jack with .75" Spacing. Color - Black.

Materials
Banana jack insulation	Polycarbonate molded to banana jack bodies.
Color	One Red, one Black, and one Green.
Mounting Plate	Polycarbonate.
Color	See ordering instructions.
Insulator	Polycarbonate. Color matches color of banana jack insulation.
Lockwasher ¼ Int tooth
Material	Steel.
Finish	Nickel plated per QQ-N-290
Hex nut ¼-32
Material	Brass.
Finish	Nickel plated per QQ-N-290.
Banana jack body/solder turret
Material	Brass, per QQ-B-626, Alloy 360, ½ Hard.
Finish	Bright tin plated per MIL-T-10727.
Ratings
Operating Temperature	+115°C. (+239°F.) Max.
Voltage
Hand-held testing	30VAC/60VDC Max.
Hands free testing in controlled voltage environments	2500 WVDC Max.
Current	15 Amperes
