Phenix 6CP15-3 15kVAC, 200mA Capacitive Load (50% Gapped Core)

Name: Phenix 6CP15-3 15kVAC, 200mA Capacitive Load (50% Gapped Core)
Brand: Phenix
SKU: Phenix6CP15-3
Price: 7700.00 USD
Availability: InStock

0 reviews | Model: Phenix 6CP15-3

Compare

15kVAC, 200mA Capacitive Load (50% Gapped Core)

Cannot Ship Air

High Accuracy: +/- 1% of FS
Featuring 3½ digit, digital LCD display output voltmeter and current meter for easy reading even in direct sunlight
Lightweight portability
Ruggedly constructed cases for years of field use
Output Termination: Toroid with output lead
Zero start (safety interlock feature)
Internal Short circuit protection
Adjustable overcurrent trip from 10% to 110% of rating
50kV AC hipot, multi-purpose, rugged design tests breakers, switchgear and many other apparatus
40 mA of output current independent of test specimen type (resistive or capacitive)
Two piece construction
External interlock provision
Made in the USA

View Product Details

List Price: $7,700.00

In Stock:

View Payment Options

Recommended for you

Phenix offers the premier line of portable AC Dielectric Test Sets with ratings from 15 to 200 kVAC which are suited for testing a wide range of electrical equipment. These units are lightweight and ruggedly constructed for field use. Each unit provides easy to read digital instrumentation and clean efficient controls.

Input	120 VAC, 60 Hz, single phase, 2kVA, 20amps or 220 VAC, 50 Hz, single phase, 2kVA, 11amps
Output	0-50kV AC, 40 mA
Duty cycle	5 min ON/15 min OFF @ 40mA
Distortion	less than 5%
Metering	Single range voltmeter: 0-50 kVAC Single range ammeter: 0-40 mA
Dimensions
Controls	16.5" W x 15.25" D x 11.25" H (419 mm) (388mm) (286 mm)
Weight	31 pounds (14 kg)
HV Transformer	15” W x 15” D x 16.5” H (381 mm) (381 mm) (419 mm)
Weight	79 pounds (36 kg)
Cables	6 ft. (2m) input power 10 ft. (3m) interconnect (2 pcs.) 10 ft. (3m) ground 5 ft. (1.5m) output lead
Options	Custom cable lengths available
