Phenix 650-2P Portable AC Dielectric Test Set

Name: Phenix 650-2P Portable AC Dielectric Test Set
Brand: Phenix
SKU: Phenix650-2P
Price: 6000.00 USD
Availability: InStock

0 reviews | Model: Phenix 650-2P

Compare

50kVAC, 40 mA, AC Hipot - INPUT VOLTAGE MUST BE SPECIFIED: Either 115-120 VAC, 60Hz or 220/240VAC 50/60 Hz

High Accuracy: +/- 1% of FS
Featuring 3½ digit, digital LCD display output voltmeter and current meter for easy reading even in direct sunlight
Lightweight portability
Ruggedly constructed cases for years of field use
Output Termination: Toroid with output lead
Zero start (safety interlock feature)
Internal Short circuit protection
Adjustable overcurrent trip from 10% to 110% of rating
50kV AC hipot, multi-purpose, rugged design tests breakers, switchgear and many other apparatus
40 mA of output current independent of test specimen type (resistive or capacitive)
Two piece construction
External interlock provision
Made in the USA

View Product Details

List Price: $6,000.00

In Stock:

View Payment Options

Recommended for you

Phenix offers the premier line of portable AC Dielectric Test Sets with ratings from 15 to 200 kVAC which are suited for testing a wide range of electrical equipment. These units are lightweight and ruggedly constructed for field use. Each unit provides easy to read digital instrumentation and clean efficient controls.

Input	120 VAC, 60 Hz, single phase, 2kVA, 20amps or 220 VAC, 50 Hz, single phase, 2kVA, 11amps
Output	0-50kV AC, 40 mA
Duty cycle	5 min ON/15 min OFF @ 40mA
Distortion	less than 5%
Metering	Single range voltmeter: 0-50 kVAC Single range ammeter: 0-40 mA
Dimensions
Controls	16.5" W x 15.25" D x 11.25" H (419 mm) (388mm) (286 mm)
Weight	31 pounds (14 kg)
HV Transformer	15” W x 15” D x 16.5” H (381 mm) (381 mm) (419 mm)
Weight	79 pounds (36 kg)
Cables	6 ft. (2m) input power 10 ft. (3m) interconnect (2 pcs.) 10 ft. (3m) ground 5 ft. (1.5m) output lead
Options	Custom cable lengths available

Tech Specs

Safety Testing / Surge Testing/Hipot Tester Template
Test Type Hipot	AC
Max AC Test Voltage	50 kV
Min AC Test Voltage	0 V
Max Trip Current AC Test	40 mA
Min Trip Current AC Test	40 mA
Programmable (hipot)	No
Insulation Resistance Test	No
Connection Type	Probe
Arc Detection	No
Scanning control capable for Multipoint Testing	No
Test Equipment General Attributes
Warranty	18 MONTHS (1.5 YEARS)
Product Weight	110 LBS
Product Height	16.00 IN
Product Length	21.00 IN
Product Width	21.00 IN
Data Logging	No
HTS/Schedule B Number	9030.33.0080
Calibration Included	NIST Calibration
Power Supply Voltage	120V 50/60 Hz, 220V Only
Country of Origin	United States
Shipping Height	16.00 IN
Shipping Length	21.00 IN
Shipping Width	21.00 IN
