Phenix MRM-10E-230 Micro-Ohm Meter with Enchanced Accuracy

Name: Phenix MRM-10E-230 Micro-Ohm Meter with Enchanced Accuracy
Brand: Phenix
SKU: PhenixMRM-10E-230
Price: 4840.00 USD
Availability: InStock

0 reviews | Model: Phenix MRM-10E-230

Compare

MRM-10, 10A Max, 0.1 Micro Ohm Res. Battery/Line Power

10A Max, 0.1 Micro Ohm Res. Battery/Line Power (230V)
Microprocessor controlled
4-wire Kelvin measurement
Easy to read digital screen display
IEC safety compliant
Separate Cable/Accessory carrying case

View Product Details

Your Price: $4,840.00

Sign-in for EDU Pricing!

In Stock:

View Payment Options

Request Quote

Non-Cancellable / Non-Returnable

Items in This Series



Product	Phenix MRM-10E-230 MRM-10, 10A Max, 0.1 Micro Ohm Res. Battery/Line Power	Phenix MRM-10E MRM-10, 10A Max, 0.1 Micro Ohm Res. Battery/Line Power (120V)	Phenix MRM-10EV2 MRM-10, 10A Max, 0.1 Micro Ohm Res. Battery/Line Power with enhanced accu ...	Phenix MRM-10EV2-230 MRM-10, 10A Max, 0.1 Micro Ohm Res. Battery/Line Power with enhanced ...	Phenix MRM-100V2 MRM-100A, 100A Max Current 0.1 Micro Ohm Resolution W/ built in printer-I ...	Phenix MRM-100V2-230 MRM-100A, 100A Max Current 0.1 Micro Ohm Resolution W/ built in print ...	Phenix MRM-200V2 MRM-200, 200A Max Current 0.1 Micro Ohm Resolution - Increased Accuracy	Phenix MRM-200V2-230 MRM-200, 200A Max Current 0.1 Micro Ohm Resolution - Increased Accura ...
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Phenix MRM-10E-230 Micro-Ohm Meters MRM Series (230V) with Enhanced Accuracy

10A Max, 0.1 Micro Ohm Res. Battery/Line Power (230V)
Microprocessor controlled
4-wire Kelvin measurement
Easy to read digital screen display

Phenix Technologies’ Microhmmeters are your contact resistance testing solution. The MRM Series will accurately measure very low contact resistances on all types of electrical products including motors, switchgear, breakers, busbars, generators, reclosers, transformers.

General Specifications
Model	MRM-10	MRM-10E	MRM-100	MRM-200
Test Current	1mA - 10A	1mA - 10A	10A - 105A	5A - 200A (True DC)
Resistance Ranges	0-2000μΩ @ 10A 0-20mΩ @ 10A 0-200mΩ @ 1A 0-2000mΩ @ 100mA 0-20Ω @ 10mA 0-200Ω @ 1mA	0-2000μΩ @ 10A 0-20mΩ @ 10A 0-200mΩ @ 1A 0-2000mΩ @ 100mA 0-20Ω @ 10mA 0-200Ω @ 1mA	1μΩ to 240mΩ	0.1μΩ to 2mΩ, with 0.1μΩ resolution 2mΩ to 200mΩ, with 10μΩ resolution 200mΩ to 1Ω, with 1mΩ resolution
Resolution	1μΩ @ 10A	0.1μΩ @ 10A	1μΩ to 199μΩ: 0.1μΩ 200μΩ to 1999μΩ: 1.0μΩ 2.00mΩ to 19.99mΩ: 0.01mΩ 20.0mΩ to 240.0mΩ: 0.1mΩ	up to 0.1μΩ
Input	100-240V, 50/60Hz	100-240V, 50/60Hz	120VAC, 60Hz or 230VAC, 50/60Hz, 5A	100-240V, 50/60Hz
Basic Accuracy	±( 0.2% of reading ±2 digits)	±(0.1% of reading + 0.005% of full scale)	±(1% of reading ±0.4μΩ at 100A) or (±4μΩ at 10A)	±0.5% of measured value
Protection	N/A	N/A	Thermal	Overcurrent, short-circuit and thermal
Operating Temperature	-5°C to 50°C	-5°C to 50°C	-5°C to 50°C	-5°C to 50°C
Storage Temperature	-25°C to 65°C	-25°C to 65°C	-20°C to 57°C	-10°C to 60°C
Humidity	<90%, non-condensing	<90%, non-condensing	<90%, non-condensing	<90%, non-condensing
Advanced Features	Powered by rechargeable battery Measured value display hold function	Powered by rechargeable battery Measured value display hold function	Full Keypad - Allows easy entry of test descriptions and parameters Integrated printer	Programmable set-up test time 5-120 seconds Software w/ automatic report generator, including operator's comments Built-in memory with capacity to store 50 registers with 80 readings each
Dimensions (L x W x H)	15" (378mm) x 12" (308mm) x 7" (175mm)	15" (378mm) x 12" (308mm) x 7" (175mm)	16.5" (419mm) x 15.25" (387mm) x 11.25" (286mm)	20" (502mm) x 15.5" (394mm) x 7.5" (190mm)
Weight	19 lbs (8.7 kgs)	17 lbs (7.6 kgs)	28 lbs (13 kgs)	45 lbs (20.5 kgs)

Tech Specs

Micro / Milli / Meg Ohmmeters/Micro-Ohmmeter / DLRO / Bond Testing Template
Style (Micro-Ohmmeter)	Portable
Maximum Test Current	10 A
Variable Test Current	Yes
Line Power or Battery power	Line Power
Kelvin Four-Terminal Measurement	Yes
Test Equipment General Attributes
Warranty	1 YEARS
Product Weight	17 LBS
Product Height	7 IN
Product Length	15 IN
Product Width	12 IN
HTS/Schedule B Number	9030.33.0080
Power Supply Voltage	120V/220V Universal, Battery Powered
Country of Origin	United States
Shipping Height	12.00 IN
Shipping Length	7.00 IN
Shipping Width	15.00 IN
