Loop Calibrator (0/4 - 20-mA signals)
Calibrator PCE-LOC 10
Process calibrator for 0/4 - 20-mA signals / Simulation of active and passive sensors / 24V DC encoder / Measurement of process currents possible
The process calibrator is used to simulate 0/4 - 20-mA signals. The process calibrator can be used to calibrate display devices, data loggers, process recorders, etc. The process calibrator can also be used to measure the process signal 0/4 ... 20-mA to test sensors and transmitters. The process calibrator is able to simulate both active sensors (source) and passive sensors (sink).
The process value can be set directly using the buttons on the process calibrator. However, it is also possible for the process calibrator to run an automatic ramp. As a further feature, the process calibrator can also provide 24V DC for sensors in order to test them in the process before commissioning. The output current from the sensor can be measured at the same time.
