| MB Series Moisture Analyzers Specifications |
| | ![]()
| ![]()
| ![]()
| ![]()
|
| Capacity | 45g | 35g | 110g | 110g |
| Repeatability (Std Dev) (g) | 0.05% (3g sample)
0.015% (10g sample) | 0.18% (3g sample)
0.02% (10g sample) | 0.2% (3g sample)
0.05% (10g sample) | 0.3% (3g sample)
0.2% (10g sample) |
| Readability | 0.01% / 0.001g | 0.02% / 0.002g | 0.05% / 0.005g | 0.1% / 0.01g |
| Sample Size | 3g to 20g typical, 0.5g min |
| Output | Bidirectional RS-232 w/ GLP/GMP | Bidirectional RS-232 |
| Heating Technology | Halogen with ramped voltage to save bulb life | Infrared (no glass) |
| Temperature Range | 50°C to 200°C in 1° increments | 50°C to 160°C in 5° increments |
| Heating Options | 4 (Fast, Standard, Ramp, Step) | (1) Standard |
| Shutoff / Timing Criteria | Manual, Custom, pre set
1-120 minutes in 10-second
increments or Auto | Manual, 1-120 min, 30-ses. Inc. to
60 min 1 min. incr. from 60 - 120
min or Auto | Manual, Timed 1 - 99 minutes, 30-second increments
to 60 minutes, or Auto |
| Power | 120, 240 VAC 50/60 Hz | 100 to 240 VAC, 50/60 Hz |
| Tare Range | To capacity by subtraction |
| Operating Temperature Range | 41° to 104°F / 5° to 40°C |
| Calibration | Weight and temperature calibration (masses and temperature kit sold separately) |
| Display Type | 128 x 64 pixel dot matrix backlit LCD display | Custom backlit LCD |
| Test Database | 50 procedure test library | N/A |
| Result Displays | % moisture, % solids, % Regain,
statistics, time, temperature,
weight (g), test ID, drying curve | % moisture, actual weight (g),
actual temperature and test time | % moisture or % solids or weight (g), temperature, time |
| Display Language | English, Spanish, French,
Italian, German | English, Spanish, French | English |
| Pan Size (Diameter) | 3.5 inch / 90 mm |
| Dimensions (W x H x D) | 7.5 x 6 x 14.2 inches / 19 x 15.2 x 36 cm | 6.5 x 5 x 11 inches / 17 x 13 x 28 cm |
| Net Weight | 10.1 lb / 4.6 kg | 5 lb / 2.3 kg |
| Shipping Weight | 14.1 lb / 6.4 kg | 8.5 lb / 3.9 kg |
| % Readability | 0.01% | 0.02% | 0.05% | 0.1% |
| Repeatability 3g (%) | 0.05% | 0.18% | 0.2% | 0.3% |
| Repeatability 10g (%) | 0.015% | 0.02% | 0.05% | 0.2% |
| Capacity × Readability | 45g × 0.001g | 35g × 0.002g | 110g × 0.005g | 110g × 0.01g |
| Heat Source | Halogen Lamp | Halogen Lamp | Halogen Lamp | Infrared Coil |
| Display Type | Graphical | Graphical | Backlit LCD | Backlit LCD |
| Display Language | English, Spanish, French,
Italian, German | English, Spanish, French, | English | English |
| Heat Range | 50-200 (1 Incr) | 50-160 (5 Incr) | 50-160 (5 Incr) | 50-160 (5 Incr) |
| Shutoff Criteria | Manual, Custom, pre set
1-120 minutes in 10-second increments or Auto | Manual, 1-120 min, 30-ses.
Inc. to 60 min 1 min. incr. from 60 - 120 min or Auto | Manual, Timed or Auto | Manual, Timed or Auto |
| Heating Profiles | Fast, Std, Ramp, Step | Standard | Standard | Standard |
| Display Results | % moisture, % solids,
% regain, time, temp,
weight, test ID, drying
curve & statistics | % moisture,
Actual Weight,
Time, Temp | % moisture, % solids,
Actual Weight,
Time, Temp | % moisture, % solids,
Actual Weight,
Temp |
| Library | 50 Procedures | NA | NA | NA |
| Applications |
| Textiles/Cotton | | |  | |
| Food | | | | |
| Waste water | | | | |
| Quality Control | | | | |
| Agriculture | | | | |
| Any Oven | | | | |
