| Models |
D51P100HL2 |
D51P150HX2 |
D51P300HX2 |
| |
![]() |
![]() |
![]() |
| Capacity x Default Readability |
250 lb x 0.05 lb
4,000 oz x 1 oz
250 lb : 1 oz
100 kg x 0.02 kg
100,000 g x 20 g |
300 lb x 0.05 lb
4,800 oz x 1 oz
300 lb : 1 oz
150 kg x 0.02 kg
150,000 g x 20 g |
600 lb x 0.1 lb
9,600 oz x 2 oz
600 lb : 2 oz
300 kg x 0.05 kg
300,000 g x 50 g |
| Maximum Displayed Resolution |
1:5,000 |
1:7,500 |
1:6,000 |
| Capacity x Certified/Approved Readability |
250 lb x 0.1 lb
100 kg x 0.05 kg |
300 lb x 0.1 lb
150 kg x 0.05 kg |
600 lb x 0.2 lb
300 kg x 0.1 kg |
| Maximum Certified Resolution |
1:2,500 |
1:3,000 |
1:3,000 |
| Indicator Model |
T51P |
| Column |
26.8 in / 680 mm painted steel |
| Construction |
ABS plastic indicator, stainless steel removable weighing platform, painted steel column and base construction, aluminum loadcell |
| Safe Overload Capacity |
150% of maximum capacity |
| Protection |
Dry use for scale, IP67 for loadcell |
| Weighing Units |
lb, oz, lb:oz, kg, g, metric tonnes, custom unit |
| Modes |
Static Weighing, Dynamic Weighing, Counting, Checkweighing, Percent Weighing, Display Hold |
| Display |
1 in / 25mm high 6-digit, 7-segment bright white backlit LCD |
| Keyboard |
4-button membrane switch |
| Stabilization Time |
Within 2 seconds |
| Auto-zero Tracking |
Off, 0.5, 1 or 3 d |
| Zeroing Range |
2% or 100% of capacity |
| Calibration |
Span: 1kg or 1lb to 100% of capacity / 3-point linearity (0 - 50% – 100% fixed) |
| Power |
100-240 VAC / 50-60Hz internal universal power supply, 6 ‘C’ cell batteries (not supplied) with 80 hour life |
| Interface |
RS232 and external input |
| Operating Temperature Range |
14°F to 104°F / -10°C to 40°C |
Scale Dimensions
(W x H1 x H2 x D1 x D2) |
15.7 x 4.1 x 37 x 19.7 x 24.4 in
400 x 105 x 940 x 500 x 620 mm |
16.5 x 4.9 x 37 x 21.7 x 26.4 in
420 x 125 x 940 x 550 x 670 mm |
Shipping Dimensions
(L x W x H) |
29.1 x 27.2 x 9.1 in
740 x 690 x 230 mm |
29.5 x 30 x 9.1 in
750 x 710 x 230 mm |
| Approx. Net Weight |
49.1 lb / 22.3 kg |
61.1 lb / 27.7 kg |
| Approx. Shipping Weight |
Net Weight- 24kg
Gross Weight- 26.5kg |
Net Weight- 30kg
Gross Weight- 32kg |
Net Weight- 32kg
Gross Weight- 32kg |
