| Defender™ 3000 Bench Scales Specifications |
| |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Capacity x
Readability (d)
(Default:
cal unit kg) |
66 lb x 0.02 lb
1056 oz x 0.2 oz
66 lb x 0.2 oz (lb:oz)
30 kg x 0.005 kg
30,000 g x 5 g |
132 lb x 0.05 lb
2,112 oz x 0.5 oz
160 lb x 0.5 oz (lb:oz)
60 kg x 0.01 kg
60,000 g x 10 g |
132 lb x 0.05 lb
2,112 oz x 0.5 oz
160 lb x 0.5 oz (lb:oz)
60 kg x 0.01 kg
60,000 g x 10 g |
330 lb x 0.05 lb
5,280 oz x 1 oz
300 lb x 1 oz (lb:oz)
150 kg x 0.02 kg
150,000 g x 20 g |
330 lb x 0.05 lb
5,280 oz x 1 oz
300 lb x 1 oz (lb:oz)
150 kg x 0.02 kg
150,000 g x 20 g |
660 lb x 0.2 lb
10,576 oz x 2 oz
660 lb x 2 oz (lb:oz)
300 kg x 0.05 kg
300,000 g x 50 g |
Capacity x
Readability (d)
(Cal unit lb) |
60 lb x 0.01 lb
960 oz x 0.2 oz
60 lb x 0.2 oz (lb:oz)
27 kg x 0.005 kg
27,000 g x 5 g |
150 lb x 0.02 lb
2,400 oz x 0.5 oz
150 lb x 0.5 oz (lb:oz)
68 kg x 0.01 kg
68,000 g x 10 g |
150 lb x 0.02 lb
2,400 oz x 0.5 oz
150 lb x 0.5 oz (lb:oz)
68 kg x 0.01 kg
68,000 g x 10 g |
300 lb x 0.05 lb
4,800 oz x 1 oz
300 lb x 1 oz (lb:oz)
136 kg x 0.05 kg
136,000 g x 50 g |
300 lb x 0.05 lb
4,800 oz x 1 oz
300 lb x 1 oz (lb:oz)
136 kg x 0.05 kg
136,000 g x 50 g |
600 lb x 0.1 lb
9,600 oz x 2 oz
600 lb x 2 oz (lb:oz)
272 kg x 0.05 kg
272,000 g x 50 g |
Maximum Displayed
Resolution |
1:6,000 |
1:7,500 |
1:7,500 |
1:7,500 |
1:7,500 |
1:6,000 |
| Scale Protection |
NEMA 4X / IP65 |
| Base Construction |
304 stainless steel pan with stainless steel frame, non-slip rubber leveling feet |
| Platform Dimensions (WxDx min H) |
12 x 14 x 4.8 in / 305 x 355 x 123 mm |
16.5 x 21.6 x 5.4 in / 420 x 550 x 136 mm |
19.7 x 25.6 x 5.8 in / 500 x 650 x 147 mm |
Front View Dimensions
(F1 x F2 x F3 x F4 x F5 x F6) |
8.2 x 6.5 x 12 x 4.8 x 3 x 10 in
210 x 166 x 305 x 119 x 75 x 256 mm |
8.2 x 6.5 x 16.5 x 5.4 x 3.2 x 14.6 in
210 x 166 x 420 x 145 x 80 x 371 mm |
8.2 x 6.5 x 19.7 x 5.6 x 3.5 x 17.3 in
210 x 166 x 500 x 154 x 90 x 440 mm |
Side View Dimensions
(S1 x S2 x S3 x S4 x S5) |
22.5 x 18.6 x 14 x 12 x 2 in
572 x 472 x 355 x 306 x 52 mm |
36.2 x 26.3 x 21.7 x 19.7 x 2 in
920 x 668 x 550 x 500 x 52 mm |
36.2 x 29.1 x 25.6 x 23.2 x 2 in
920 x 740 x 650 x 590 x 52 mm |
| Column |
13.8 in / 350 mm fixed height,
stainless steel |
27.6 in / 700 mm fixed height, stainless steel |
| Leveling Component |
Externally visible level bubble and adjustable leveling feet with locking nuts |
| Safe Overload Capacity |
125% of rated capacity |
| Indicator Construction |
Stainless steel |
| Weighing Units |
lb, oz, lb:oz, kg, g |
| Functions |
Weighing, Parts Counting |
| Weight Display |
6-digit, 7-segment backlit LCD, 1 inch / 25 mm high digits |
| Keyboard |
4 function mechanical keys, raised, tactile |
| Stabilization Time |
Within 2 seconds |
| Auto-zero Tracking |
Off, 0.5, 1 or 3 divisions |
| Key Zeroing Range |
2% or 100% of capacity |
| Span Calibration |
5 lb/kg to 100% of capacity, user selectable |
| Power |
100 - 240 VAC/50-60 Hz internal switching power supply with internal rechargeable sealed lead-acid battery
(58-hour typical operation with full charge) |
| Interface |
Bidirectional RS232C |
| Operating Temperature Range |
14°F to 104°F / -10°C to 40°C,
Maximum relative humidity 80 % for temperatures up to 88°F / 31°C,
decreasing linearly to 50 % relative humidity at 104°F / 40°C, non condensing |
| Net Weight |
33 lb / 15 kg |
53 lb / 24 kg |
60 lb / 27 kg |
84 lb / 38 kg |
| Shipping Weight |
41 lb / 19 kg |
61 lb / 28 kg |
67 lb / 30 kg |
96 lb / 44 kg |
| Shipping Dimensions |
25.3 x 19.6 x 8.5 in /
642 x 497 x 212 mm |
33.7 x 22.2 x 8.9 in /
857 x 564 x 225 mm |
40.2 x 27 x 9.7 in /
1022 x 687 x 247 mm |
