| Model: i-DT61PW AM Front Specifications |
| Construction |
Polycarbonate plastic housing, 316 stainless steel bracket |
| Protection |
IP68 immersion / IP69K washdown |
| A/D Conversion Rate |
80hz |
| Capacity Selection |
Up to 99,999 g/kg/lb/t |
| Maximum Displayed Resolution |
1:75,000 |
| Maximum Approved Resolution |
1:10,000 (NTEP: III, IIIL, Measurement Canada: III, IIIHD) @ 2 mV/V |
| Weighing Units |
Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric Tonne) |
| Application Modes |
Weighing, Checkweighing, Percent Weighing, Dynamic Weighing/Display Hold, Counting with APW optimization, Checkcounting, Filling (i-DT61XWE only) |
| Display |
6-digit, 7-segment LCD display with white backlight, 45 mm / 1.8 in high digits |
| Check Indicator |
3 Color (red, green, yellow) LED Bar |
| Keyboard |
6 function mechanical keys |
| Auto-Zero Tracking |
Off, 0.5 d, 1 d or 3 d |
| Zeroing Range |
2% or 100% of capacity |
| Calibration |
Zero, Span or 3 point-Linear |
| Span Calibration |
1 lb or 1 kg to capacity |
| Internal Resolution |
1,000,000 counts per mV/V |
| Digital Filtering/Type |
Averaging |
| Load Cell Excitation Voltage |
3.3VDC |
| Load Cell Drive |
Up to 4 x 350 ohm load cells |
| Load Cell Input Sensitivity |
Up to 3 mV/V |
| Stabilization Time |
Within 1.5 seconds |
| Power |
6 x D type cell battery |
| Battery Life |
Up to 1600 hours continuous use with backlight off |
| Interface |
Optional IR Communication Kit (with magnetic front panel connection) |
| Shipping Dimensions |
11.8 x 10.4 x 5.3 in / 300 x 265 x 135 mm |
| Product Dimensions (With Bracket) |
10.4 x 8.9 x 3.3 in / 265 x 225 x 85 mm |
| Approx. Net Weight |
6.0 lb / 2.7 kg |
| Approx. Shipping Weight |
8.4 lb / 3.8 kg |
| Operating Temperature Range |
14 °F to 104 °F / -10 °C to 40 °C |
