Capacity x Default Readability |
100 lb x 0.01 lb
50 kg x 5 g |
Maximum Displayed Resolution |
1:10,000 |
Linearity/Repeatability |
±2d |
Capacity x Certified/Approved Readability |
100 lb x 0.02 lb
50 kg x 10 g |
Maximum Certified Resolution |
1:5,000 |
Indicator |
i-DT61XWE |
Column |
26.4 in / 670 mm 316 stainless steel |
Base Construction |
316 stainless steel removable weighing platform with 316 stainless steel frame, hermetically sealed IP68/ IP69K stainless steel loadcell |
Safe Overload Capacity |
150% of maximum capacity |
Stabilization Time |
Within 1 second |
Operating Temperature Range |
14 °F to 104 °F / -10 °C to 40 °C |
Scale Dimensions (A x B x C x D x E x F) |
19.7 x 15.7 x 5.4 x 3.1 x 36.6 x 26 in
500 x 400 x 137 x 80 x 929 x 660 mm |
Shipping Dimensions (L x W x H) |
39.4 x 27.2 x 9.8 in
1000 x 690 x 250 mm |
Approx. Net Weight |
48.5 lb / 22 kg |
Approx. Shipping Weight |
55.1 lb / 25 kg |
Model |
i-DT61XWE |
Construction |
316 Stainless steel housing, 316 stainless steel bracket |
Protection |
IP68 immersion / IP69K washdown |
A/D Conversion Rate |
80 Hz |
Capacity Selections |
999,999 kg/lb with decimal located to five places |
Maximum Displayed Resolution |
1:75,000 |
Maximum Approved Resolution |
1:10,000 (NTEP: III, IIIL, Measurement Canada: III, IIIHD) @ 1.6 mV/V |
Weight Units |
Kilogram, Gram, Pound, Ounce, Pound: Ounce |
Application Modes |
Weighing, Checkweighing, Percent Weighing, Dynamic Weighing/Display Hold, Counting with APW optimization, Checkcounting, Filling (i-DT61XWE only) |
Display |
6-digit, 7-segment white LED, 20 mm / 0.8 in high digits |
Check Indicator |
3 color (red, green, orange) 8x16 dot matrix LED |
Keyboard |
6 function keys + 12 numeric capacitive keypad |
Auto-Zero Tracking |
Off, 0.5 d, 1 d, or 3 d |
Zeroing Range |
2% or 100% of capacity |
Calibration |
Zero, Span or 3 point-Linear |
Span Calibration |
1 lb or 1 kg to capacity |
Internal Resolution |
1,137,000 counts per mV/V |
Digital Filtering/Type |
Averaging |
Load Cell Excitation Voltage |
5VDC |
Load Cell Drive |
Up to 8 x 350-ohm load cells |
Load Cell Input Sensitivity |
Up to 3 mV/V |
Stabilization Time |
Within 1 second |
Power |
100-240 VAC / 50/60 Hz Universal Power Supply, hardwired or external power bank |
Battery Life |
Depends on the capacity of the power bank used (Up to 55 hours with 20000mAh power bank) |
Interface |
RS232 and USB Host included
Optional Ethernet, WiFi/Bluetooth, 2nd RS232/RS485/USB
Device, Analog Output, 2 In/4 Out Discrete I/O |
Shipping Dimensions |
11.8 x 10.4 x 5.3 in / 300 x 265 x 135 mm |
Product Dimensions (With Bracket) |
11.4 x 9.3 x 3.1 in / 290 x 235 x 80 mm |
Approx. Net Weight |
7.0 lb / 3.2 kg |
Approx. Shipping Weight |
7.7 lb / 3.5 kg |
Operating Temperature Range |
14°F to 104°F / -10°C to 40°C |
