Maximum Capacity |
50 lb (25 kg) |
Readability |
0.002 lb (1 g) |
Readability (Certified) |
0.01 lb (5 g) |
Platform Size (LxW) |
18 in x 18 in (457 mm x 457 mm) |
Legal for Trade |
NTEP Certified; Measurement Canada Approved |
Power |
7 D (LR20) Batteries (Included) |
Battery Life |
1600 Hours with Disposable Batteries |
Communication |
Infrared Radio communication kit (available as an accessory) |
Dimensions |
28.9 in x 5.1 in x 18 in (734 mm x 129 mm x 457 mm) (LxHxW) |
Display |
7-Segment LCD with white backlight, height 45mm + 3 Color Checkweigh LED |
Net Weight |
39.7 lb (18 kg) |
Outputs |
Not Applicable |
Platform Construction |
Stainless Steel |
Protection Rating |
IP69k; IP68 |
Second Scale Input |
Not Applicable |
Tare Range |
To capacity by subtraction |
Units of Measurement |
Metric Tonnes; Gram; Kilogram; Pound; Ounce; Pound: Ounce |
Model |
i-D61PW |
Construction |
Polycarbonate plastic housing, 316 stainless steel bracket |
Protection |
IP68 immersion / IP69K washdown |
A/D Conversion Rate |
80 Hz |
Capacity Selections |
Up to 99,999 g/kg/lb/t |
Maximum Displayed Resolution |
1:75,000 |
Maximum Approved Resolution |
1:10,000 (NTEP: III, IIIL, Measurement Canada: III, IIIHD) @ 2 mV/V |
Weight Units |
Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric Tonne) |
Application Modes |
Weighing, Checkweighing, Percent Weighing, Dynamic Weighing/Display Hold, Counting with APW optimization, Checkcounting, Filling (i-DT61XWE only) |
Display |
6-digit, 7-segment LCD display with white backlight, 45 mm / 1.8 in high digits |
Check Indicator |
3 Color (red, green, yellow) LED Bar |
Keyboard |
6 function mechanical keys |
Auto-Zero Tracking |
Off, 0.5 d, 1 d, or 3 d |
Zeroing Range |
2% or 100% of capacity |
Calibration |
Zero, Span or 3 point-Linear |
Span Calibration |
1 lb or 1 kg to capacity |
Internal Resolution |
1,000,000 counts per mV/V |
Digital Filtering/Type |
Averaging |
Load Cell Excitation Voltage |
3.3VDC |
Load Cell Drive |
Up to 4 x 350-ohm load cells |
Load Cell Input Sensitivity |
Up to 3 mV/V |
Stabilization Time |
Within 1.5 seconds |
Power |
6 x D type cell battery |
Battery Life |
Up to 1600 hours continuous use with backlight off |
Interface |
Optional IR Communication Kit (with magnetic front panel connection) |
Shipping Dimensions |
11.8 x 10.4 x 5.3 in / 300 x 265 x 135 mm |
Product Dimensions (With Bracket) |
10.4 x 8.9 x 3.3 in / 265 x 225 x 85 mm |
Approx. Net Weight |
6.0 lb / 2.7 kg |
Approx. Shipping Weight |
8.4 lb / 3.8 kg |
Operating Temperature Range |
14°F to 104°F / -10°C to 40°C |
