| Capacity x Default Readability |
300 lb x 0.02 lb 150 kg x 10 g |
| Maximum Displayed Resolution |
1:15,000 |
| Linearity/Repeatability |
±2d |
| Capacity x Certified/Approved Readability |
300 lb x 0.1 lb
150 kg x 50 g |
| Maximum Certified Resolution |
1:3,000 |
| Indicator |
i-DT61PW |
| Column |
26.4 in / 670 mm 316 stainless steel |
| Base Construction |
316 stainless steel removable weighing platform with 316 stainless steel frame, hermetically sealed IP68/IP69K stainless steel loadcell |
| Safe Overload Capacity |
150% of maximum capacity |
| Stabilization Time |
Within 1 second |
| Operating Temperature Range |
14 °F to 104 °F / -10 °C to 40 °C |
Scale Dimensions
(A x B x C x D x E x F) |
19.7 x 15.7 x 5.4 x 3.1 x 36 x 26 in
500 x 400 x 137 x 80 x 915 x 660 mm |
| Shipping Dimensions (L x W x H) |
39.4 x 27.2 x 9.8 in
1000 x 690 x 250 mm |
| Approx. Net Weight |
50.1 lb / 22.7 kg |
| Approx. Shipping Weight |
57.3 lb / 26 kg |
| Model |
i-D61PW |
| Construction |
Polycarbonate plastic housing, 316 stainless steel bracket |
| Protection |
IP68 immersion / IP69K washdown |
| A/D Conversion Rate |
80 Hz |
| Capacity Selections |
Up to 99,999 g/kg/lb/t |
| Maximum Displayed Resolution |
1:75,000 |
| Maximum Approved Resolution |
1:10,000 (NTEP: III, IIIL, Measurement Canada: III, IIIHD) @ 2 mV/V |
| Weight Units |
Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric Tonne) |
| Application Modes |
Weighing, Checkweighing, Percent Weighing, Dynamic Weighing/Display Hold, Counting with APW optimization, Checkcounting, Filling (i-DT61XWE only) |
| Display |
6-digit, 7-segment LCD display with white backlight, 45 mm / 1.8 in high digits |
| Check Indicator |
3 Color (red, green, yellow) LED Bar |
| Keyboard |
6 function mechanical keys |
| Auto-Zero Tracking |
Off, 0.5 d, 1 d, or 3 d |
| Zeroing Range |
2% or 100% of capacity |
| Calibration |
Zero, Span or 3 point-Linear |
| Span Calibration |
1 lb or 1 kg to capacity |
| Internal Resolution |
1,000,000 counts per mV/V |
| Digital Filtering/Type |
Averaging |
| Load Cell Excitation Voltage |
3.3VDC |
| Load Cell Drive |
Up to 4 x 350-ohm load cells |
| Load Cell Input Sensitivity |
Up to 3 mV/V |
| Stabilization Time |
Within 1.5 seconds |
| Power |
6 x D type cell battery |
| Battery Life |
Up to 1600 hours continuous use with backlight off |
| Interface |
Optional IR Communication Kit (with magnetic front panel connection) |
| Shipping Dimensions |
11.8 x 10.4 x 5.3 in / 300 x 265 x 135 mm |
| Product Dimensions (With Bracket) |
10.4 x 8.9 x 3.3 in / 265 x 225 x 85 mm |
| Approx. Net Weight |
6.0 lb / 2.7 kg |
| Approx. Shipping Weight |
8.4 lb / 3.8 kg |
| Operating Temperature Range |
14°F to 104°F / -10°C to 40°C |
