Capacity x Default Readability |
25 lb x 0.002 lb 12.5 kg x 1 g |
Maximum Displayed Resolution |
1:12,500 |
Linearity/Repeatability |
±2d |
Capacity x Certified/Approved Readability |
25 lb x 0.005 lb
12.5 kg x 5 g |
Maximum Certified Resolution |
1:5,000 |
Indicator |
i-DT61PW |
Column |
10.2 in / 260 mm 316 stainless steel |
Base Construction |
316 stainless steel top and bottom frame, hermetically sealed IP68/IP69K stainless steel loadcell |
Safe Overload Capacity |
150% of maximum capacity |
Stabilization Time |
Within 1 second |
Operating Temperature Range |
14 °F to 104 °F / -10 °C to 40 °C |
Scale Dimensions
(A x B x C x D x E x F) |
11.8 x 11.8 x 4.2 x - x 19.8 x 16.8 in
300 x 300 x 106 x - x 504 x 427 mm |
Shipping Dimensions (L x W x H) |
19.3 x 17.7 x 15 in
490 x 450 x 380 mm |
Approx. Net Weight |
24.7 lb / 11.2 kg |
Approx. Shipping Weight |
30.9 lb / 14 kg |
Model |
i-D61PW |
Construction |
Polycarbonate plastic housing, 316 stainless steel bracket |
Protection |
IP68 immersion / IP69K washdown |
A/D Conversion Rate |
80 Hz |
Capacity Selections |
Up to 99,999 g/kg/lb/t |
Maximum Displayed Resolution |
1:75,000 |
Maximum Approved Resolution |
1:10,000 (NTEP: III, IIIL, Measurement Canada: III, IIIHD) @ 2 mV/V |
Weight Units |
Kilogram, Gram, Pound, Ounce, Pound: Ounce, Tonne (Metric Tonne) |
Application Modes |
Weighing, Checkweighing, Percent Weighing, Dynamic Weighing/Display Hold, Counting with APW optimization, Checkcounting, Filling (i-DT61XWE only) |
Display |
6-digit, 7-segment LCD display with white backlight, 45 mm / 1.8 in high digits |
Check Indicator |
3 Color (red, green, yellow) LED Bar |
Keyboard |
6 function mechanical keys |
Auto-Zero Tracking |
Off, 0.5 d, 1 d, or 3 d |
Zeroing Range |
2% or 100% of capacity |
Calibration |
Zero, Span or 3 point-Linear |
Span Calibration |
1 lb or 1 kg to capacity |
Internal Resolution |
1,000,000 counts per mV/V |
Digital Filtering/Type |
Averaging |
Load Cell Excitation Voltage |
3.3VDC |
Load Cell Drive |
Up to 4 x 350-ohm load cells |
Load Cell Input Sensitivity |
Up to 3 mV/V |
Stabilization Time |
Within 1.5 seconds |
Power |
6 x D type cell battery |
Battery Life |
Up to 1600 hours continuous use with backlight off |
Interface |
Optional IR Communication Kit (with magnetic front panel connection) |
Shipping Dimensions |
11.8 x 10.4 x 5.3 in / 300 x 265 x 135 mm |
Product Dimensions (With Bracket) |
10.4 x 8.9 x 3.3 in / 265 x 225 x 85 mm |
Approx. Net Weight |
6.0 lb / 2.7 kg |
Approx. Shipping Weight |
8.4 lb / 3.8 kg |
Operating Temperature Range |
14°F to 104°F / -10°C to 40°C |
