| Valor 2000 Compact Bench Scales |
| Model |
V22PWE1501T
V22XWE1501T |
V22PWE3T
V22XWE3T |
V22PWE6T
V22XWE6T |
V22PWE15T
V22XWE15T |
V22PWE30T
V22XWE30T |
| Capacity (max) x Readability (d) |
1.5 kg × 0.0002 kg
1500 g × 0.2 g
3 lb × 0.0005 lb
48 oz × 0.01 oz
3 lb × 0.01 oz (lb:oz) |
3 kg × 0.0005 kg
3000 g × 0.5 g
6 lb × 0.001 lb
96 oz × 0.02 oz
6 lb × 0.02 oz (lb:oz) |
6 kg × 0.001 kg
6000 g × 1 g15 lb × 0.002 lb240 oz × 0.05 oz15 lb × 0.05 oz (lb:oz) |
15 kg × 0.002 kg
15000 g × 2 g30 lb × 0.005 lb480 oz × 0.1 oz30 lb × 0.1 oz (lb:oz) |
30 kg × 0.005 kg
30000 g × 5 g60 lb × 0.01 lb960 oz × 0.2 oz60 lb × 0.2 oz (lb:oz) |
| Maximum Resolution (d) |
1:7,500 |
1:6,000 |
1:6,000 |
1:7,500 |
1:6,000 |
| Weighing Units |
g, kg, lb, oz, lb:oz |
| Application Modes |
V22PW: Weighing
V22XW: Weighing, Checkweighing |
| Keyboard |
V22PW: Two mechanical switches with polycarbonate overlay
V22XW: Four mechanical switches with polycarbonate overlay |
| Calibration |
Digital external span calibration |
| Display |
7 segment, 6 digit, 20.5 mm / 0.8 in high red LED dual display |
| Display Indicators |
Stability, center of zero, net, battery status |
| Tare Range |
To capacity by subtraction |
| Zero Range |
-10% to 10% of Capacity |
| Stabilization Time |
≤0.5 second |
| Safe Overload Capacity |
150% of capacity |
| Operation Temperature Range |
-10 º C to 40 º C / 14° F to 104° F, 10% to 90% relative humidity non-condensing |
| Construction |
V22PW: stainless steel platform, ABS housing
V22XW: Stainless steel top housing and platform, ABS bottom housing |
| Power |
12V DC 0.84A, AC Universal adapter (100 - 220V AC / 50 -60Hz) and built-in internal rechargeable lead acid battery included |
| Battery Operation |
Typically 50 hours of continuous use with 12-hour full charge |
| Ingress Protection |
IPX8 Washdown |
| Pan Size |
190 × 242 mm / 7.5 × 9.5 in |
| Scale Dimensions (W × D × H) |
V22PW: 256 × 280 × 121 mm / 10.1 × 11 × 4.8 in
V22XW: 256 × 288 × 124 mm / 10.1 × 11.3 × 4.9 in |
| Shipping Dimensions (W × D × H) |
410 × 370 × 220mm / 16.1 × 14.6 × 8.7 in |
| Net Weight |
V22PW: 3.0 kg / 6.6 lb
V22XW: 3.9 kg / 8.6 lb |
| Shipping Weight |
V22PW: 4.0 kg / 8.8 lb
V22XW: 4.9 kg / 10.8 lb |
