| Calibration |
All models feature external calibration. Models feature AutoCal™ internal calibration, except for EX.../E models |
| Tare Range |
To capacity by subtraction |
| Power Requirements |
AC Adapter Input: 100-240 VAC, 0.6A, 50-60 Hz |
| Display Type |
Full-color VGA graphic display, 4-wire resistive touch screen |
| Display Size |
5.7 in / 145 mm (diagonal) |
| Display Housing (W×H×D) |
7.68 × 3.54 × 6.06 in / 195 × 90 × 154 mm |
| Base Housing (W×H×D) |
9.06 × 13.78 × 15.47 in / 230 × 350 × 393 mm |
| Communication |
RS232, USB and optional ethernet or 2nd RS232 |
| Temperature Range |
50°F to 86°F / 10°C to 30°C |
| Humidity Range |
80% max up to 86°F/30°C decreasing linearly to 50% at 104°F/40°C, non-condensing |
| Storage Conditions |
140°F/60°C at 10% to 90% relative humidity, non-condensing |
| Net Weight |
15 lbs / 6.9 kg |
| Shipping Weight |
21 lbs / 9.6 kg |
| Shipping Dimensions |
21.65 × 15.16 × 21.69 in / 55 × 38.5 × 55.1 cm |
| Weighing Units |
Gram, Milligram, Kilogram, Carat, Ounce, Ounce Troy, Pound, Pennyweight, Grain, Newton, Momme, Mesghal, Hong Kong Tael, Singapore Tael, Taiwan Tael, Tical, Tola, Baht, Custom Unit 1, Custom Unit 2, Custom Unit 3 |
| Weighing Applications |
Weighing, Percent Weighing, Parts Counting, Check Weighing, Dynamic/Animal Weighing, Filling, Totalization, Formulation, Differential Weighing, Density Determination, Peak Hold, Ingredient Costing, Pipette Adjustment, SQC |
| Display |
High resolution 14.5cm (diagonal) full colour VGA touch display including QWERTY and numeric key pads plus weighing capacity indication |
