| General Specifications |
| Dimensions |
3.5 in x 7.8 in x 1.9 in (8.9 cm x 19.8 cm x 4.8 cm) |
| Weight |
18 oz (0.5 kg) |
| Battery |
Removable, rechargeable lithium-ion battery pack (18.5 Watt-hrs) |
| Battery Life |
Typical operating life is 6 hours; Typical charge time is 3 hours |
| External AC Adapter/Charger |
AC input 90 to 264V AC 48 to 62 Hz input power DC output 15V DC at 1.2 Amps |
| Display |
2.8 in color LCD (320 x 240 pixels) |
| Keypad |
12-key elastomeric |
| Tone Generator |
IntelliTone™ digital tone: [500 KHz]; analog tones: [400 Hz, 1 KHz] |
| Media Access; Copper |
RJ-45: 10BASE-T, 100BASE-TX, 1000BASE-T and PoE (IEEE 802.3af and 802.3at) |
| Media Access; Fiber |
SFP Adapter Port supports 100BASE-FX and 1000BASE-LX/ SX/ZX (LRAT-2000 Only) |
| Cable Tests |
Pair lengths, opens, shorts, splits, crossed, straight through, and cable ID |
| Power over Ethernet (PoE) |
Single ended testing:
User-defined testing to IEEE 802.3at class 0, 1, 2, 3, 4 without LLDP negation, or 4 with LLDP negotiation
The following PSE PoE parameters are measured:
Pairs used
Received class
PSE type
Unloaded voltage(V)
Loaded voltage (V) (LRAT-2000 with TruePower™)
Unloaded power (W) (LRAT-1000)
Loaded power (W) (LRAT-2000 with TruePower™) |
| Supporting Operating Systems |
Windows® 8.1 and Windows® 10
Minimum hardware requirement:
Processor: 1 GHz or better CPU
RAM: 1 GB or more
Hard Disk: 1 MB available space
Display: 1024 x 768 high color, 32-bit (recommended)
Interface: USB |
| Environmental |
| Operating Temperature and Relative Humidity |
32°F to 113°F (0°C to +45°C) Note: The battery will not charge if the internal temperature of the tester is above 113°F (45°C) |
| Operating Relative Humidity (% RH without condensation) |
90% (50°F to 95°F; 10°C to 35°C) 75% (95°F to 113°F; 35°C to 45°C) |
| Storage Temperature |
-4°F to 140°F (-20°C to +60°C) |
| Shock and Vibration |
Random, 2 g, 5 Hz-500 Hz (Class 2) 1 m drop |
| Safety |
EN 61010-1 2nd edition |
| Altitude |
4,000 m; Storage: 12,000 m |
| EMC |
FCC Part 15 Class A, EN 61326-1 |
| Certifications and Compliance |
Conforms to relevant European Union directives Conforms to relevant Australian standards Listed by the Canadian Standards Association |
| LinkRunner AT Manager Software |
| Supporting Operating Systems |
Windows® 8.1 and Window®10 |
| Processor |
1 Ghz or better |
| RAM |
1 GB or more |
| Hard Disk |
1 GB available space |
| Display |
1024 x 768 high color, 32-bit (recommended) |
| Interface |
USB |
