| Specifications |
| System Requirements |
Requires mobile device operating with Apple iOS 6 or iOS 7. App is optimized for iOS 7 |
| Measurement Range |
Conductivity & TDS: 1-10,000 µS or ppm; Salinity 0.0010-10.000 ppt; |
| Temperature |
0°-71°C / 32°-160°F |
| Accuracy (After Wet Calibration) |
± 1% of reading; Temperature ± 0.1ºC / ± 0.1ºF |
| Resolution |
Conductivity and TDS: 0.1 for 1.0 - 99.9 µS or ppm
1 for 100 - 10.000 µS or ppm
Salinity: 0.0001 for 0.0010 - 0.0999 ppt
0.001 for 0.100 - 10.000
Temperature: 0.1 ºC or ºF |
| Repeatability |
< 1000 µS or ppm ± 1 Count
≥ 1000 µS or ppm ± 0.3% of reading |
| Time to Reading Stabilization |
10 - 20 seconds |
| Active Mode Power Consumption |
Active Mode 30 - 140 mA, Sleep Mode 2 µA |
| Temperature Compensation Method |
Automatic to 25 ºC |
| Physical Dimensions |
17.15 cm L x 1.59 cm D or 6.75 in. L x .625 in. D |
| Weight |
55 g or 1.94 oz. |
| Case Material |
Anodized Aircraft Aluminum with Protective Coating |
| Battery Type |
N type, Alkaline 1.5 V |
| Calibration Standard Solution |
KCl: 1800 µS for COND; 442™: 3000 ppm (2027 ppm NaCl) for TDS and Salinity. |
| Operating/Storage Temperature |
0 - 55ºC or 32 - 131ºF |
| Water Resistance |
IP67 and NEMA 6 |
| EN61236-1: 2006 - Annex A: 2008; 1999/5/EC Annex III |
Electrostatic discharge to the PTBT1 may cause it to spontaneously power on.
If this occurs, the PTBT1 will power off after several seconds. |
| FCC ID: T7VPAN17 |
The Bluetooth transceiver device meets the requirements for modular transmitter
approval as detailed in FCC public Notice DA00-1407. |
Canada (IC), license:
IC: 216Q-PAN17 |
The Bluetooth transceiver device meets the requirements for modular transmitter
approval as detailed in RSS-GEN. |
